Single Row Deep Groove Ball Bearings 211SX

Single Row Deep Groove Ball Bearings 211SX

The 211SX is a single-row deep groove ball bearing with a 55mm bore and 100mm outer diameter, crafted from sturdy chrome steel for reliable performance. It handles radial loads up to 10881 lbf and operates smoothly at speeds up to 7000 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures durability. The bearing works efficiently in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 0.66kg, it offers a balance of strength and manageability. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 211SX
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 55 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 100 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 21 mm
  • Width Tolerance -0.15mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 10881 lbf
  • Static Radial Load 9892 lbf
  • Max Speed 7000 rpm
  • Weight 0.66 kg
  • price（$） 37.62
Single Row Deep Groove Ball Bearings 211SX dimension drawing
Download DWG Download PDF

Features

Performance Features of 211SX Bearing

211SX Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 10881 lbf, ensuring dependable performance in various applications.

The chrome steel cage maintains ball alignment, reducing friction and extending operational life.
With a maximum speed of 7,000 rpm, it provides a balance of durability and efficiency.

211SX Bearing operates smoothly in temperatures ranging from -30°C to 120°C.
Its open design allows for easy lubrication, enhancing long-term reliability.

Application

Industrial Uses of 211SX Bearing
211SX Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures reliable performance. The open design allows for easy lubrication, extending its service life in demanding conditions.

What Makes 211SX Bearing a Preferred Choice?
In automotive applications, 211SX Bearing fits well in wheel hubs and transmissions, thanks to its durable chrome steel construction. Its metric sizing makes it a versatile option for various vehicle models.

Perfect Fit for Automation: 211SX Bearing
211SX Bearing works efficiently in robotic arms and conveyor systems, providing smooth operation under radial loads. The ABEC 1 tolerance ensures consistent performance in precision-driven tasks.

Medical vs Industrial: Where 211SX Bearing Excels
For medical devices like centrifuges, 211SX Bearing offers reliable performance with its chrome steel rings and balls. In industrial settings, it handles heavy loads in machinery like gearboxes and compressors.

Where to Use 211SX Bearing
211SX Bearing is ideal for household appliances like washing machines, where its durability and quiet operation are appreciated. The wide temperature range also makes it suitable for various environments.
