Single Row Deep Groove Ball Bearings 208MFF

Single Row Deep Groove Ball Bearings 208MFF

The 208MFF is a single-row deep groove ball bearing with a 40mm bore and 80mm outer diameter, crafted from sturdy chrome steel for reliable performance. It manages radial loads up to 7554 lbf and operates smoothly at speeds reaching 9500 RPM.

Its open design simplifies maintenance, while the chrome steel cage enhances durability. The bearing functions efficiently in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. It’s well-suited for applications like electric motors or pumps where radial loads are predominant.

Weighing 0.39kg, it balances strength and lightness. Compliant with RoHS and REACH standards, ensuring safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 208MFF
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 40 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 80 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 18 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 7554 lbf
  • Static Radial Load 6070 lbf
  • Max Speed 9500 rpm
  • Weight 0.39 kg
  • price（$） 11.313
Single Row Deep Groove Ball Bearings 208MFF dimension drawing
Download DWG Download PDF

Features

Performance Features of 208MFF Bearing

208MFF Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 7554 lbf, making it suitable for various industrial applications.

The single-row deep groove design ensures smooth operation and efficient load distribution.
With a maximum speed of 9,500 rpm, it delivers reliable performance in high-speed conditions.

208MFF Bearing operates in temperatures from -30°C to 120°C, adapting to diverse environments.
Its open seal design simplifies maintenance while maintaining durability.

The ABEC 1 tolerance class ensures consistent precision for standard applications.
This bearing is interchangeable with SKF models, providing flexibility in replacements.

Application

Industrial Uses of 208MFF Bearing
208MFF Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures smooth operation. The open design allows for easy lubrication, making it suitable for high-speed applications.

In automotive systems, 208MFF Bearing fits well in components such as alternators and wheel hubs, providing reliable performance. Its chrome steel construction offers durability under varying temperatures and loads.

For automation equipment, 208MFF Bearing supports precise movements in robotic arms and conveyor systems. The ABEC 1 tolerance ensures consistent performance in repetitive tasks.

Where Is 208MFF Bearing Used?
You’ll often find 208MFF Bearing in household appliances like washing machines and fans, where its quiet operation is a plus. The metric sizing makes it easy to replace in most European and Asian models.

In medical devices, 208MFF Bearing’s reliability is key for equipment like centrifuges and lab instruments. The chrome steel cage adds extra resistance to wear in sterile environments.

Built for Heavy-Duty Use: 208MFF Bearing
208MFF Bearing handles radial loads effortlessly in construction equipment like gearboxes and compressors. Its wide temperature range makes it adaptable to harsh working conditions.

For consumer electronics, 208MFF Bearing ensures smooth rotation in devices like printers and scanners. The lightweight design doesn’t compromise on strength or durability.
