Single Row Deep Groove Ball Bearings 207SFFG

Single Row Deep Groove Ball Bearings 207SFFG

The 207SFFG is a single-row deep groove ball bearing with a 35mm bore and 72mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 6182 lbf and operates smoothly at speeds up to 10,000 RPM.

Its open design simplifies maintenance, while the chrome steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 0.31kg, it balances strength and lightness. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 207SFFG
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 6182 lbf
  • Static Radial Load 4946 lbf
  • Max Speed 10000 rpm
  • Weight 0.31 kg
  • price（$） 7.551
Single Row Deep Groove Ball Bearings 207SFFG dimension drawing
Download DWG Download PDF

Features

Performance Features of 207SFFG Bearing

207SFFG Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 6182 lbf, ensuring reliable performance in various applications.

The single-row deep groove design of 207SFFG Bearing allows for smooth operation and reduced friction.
With a maximum speed of 10,000 rpm, it balances efficiency and durability in demanding conditions.

207SFFG Bearing operates effectively in temperatures ranging from -30°C to 120°C.
Its open seal design simplifies maintenance while maintaining performance in different environments.

The chrome steel cage in 207SFFG Bearing ensures proper ball alignment, extending its service life.
This design also reduces wear, making it a cost-effective choice for long-term use.

Application

Industrial Uses of 207SFFG Bearing
207SFFG Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures reliable performance. The open design allows for easy lubrication, making it suitable for high-speed applications.

In automotive systems, 207SFFG Bearing can be found in components such as alternators and wheel hubs, providing smooth rotation under varying loads. Its chrome steel construction offers durability in both light and heavy-duty vehicles.

For automation equipment, 207SFFG Bearing supports precise movements in robotic arms and conveyor systems. The ABEC 1 tolerance ensures consistent performance in repetitive tasks.

Where Is 207SFFG Bearing Used?
207SFFG Bearing is ideal for household appliances like washing machines and fans, where quiet operation is essential. Its metric sizing makes it compatible with a wide range of consumer products.

Built for Heavy-Duty Use: 207SFFG Bearing
207SFFG Bearing handles radial loads effectively in agricultural machinery, such as tractors and harvesters. The chrome steel cage enhances its longevity in harsh outdoor conditions.
