Single Row Deep Groove Ball Bearings 207MFF

Single Row Deep Groove Ball Bearings 207MFF

The 207MFF is a single row deep groove ball bearing with a 35mm bore and 72mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 6182 lbf and operates smoothly at speeds up to 10,000 RPM.

Its open design simplifies maintenance, while the chrome steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 0.31kg, it balances strength and lightness. Compliant with RoHS and REACH standards for safe usage.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 207MFF
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 6182 lbf
  • Static Radial Load 4946 lbf
  • Max Speed 10000 rpm
  • Weight 0.31 kg
  • price（$） 9.936
Single Row Deep Groove Ball Bearings 207MFF dimension drawing
Download DWG Download PDF

Features

Performance Features of 207MFF Bearing

207MFF Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 6182 lbf, ensuring reliable performance in various applications.
The chrome steel cage maintains ball alignment, reducing friction and wear for extended durability.
With a maximum speed of 10,000 rpm, it delivers efficient operation in demanding conditions.

Application

Key Fields for 207MFF Bearing
207MFF Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures smooth operation. The open design allows for easy lubrication, extending its service life in demanding environments.

In automotive applications, 207MFF Bearing fits well in components such as alternators and wheel hubs, providing reliable performance under varying speeds. Its metric sizing makes it a versatile choice for both domestic and international vehicle models.

For automation systems, 207MFF Bearing supports robotic arms and conveyor belts, thanks to its balanced load distribution. The chrome steel construction offers durability, making it suitable for continuous operation.

In household appliances like washing machines, 207MFF Bearing reduces noise and vibration, enhancing user comfort. Its temperature tolerance ensures stable performance even during extended use.
