Single Row Deep Groove Ball Bearings 207-KPPB3

Single Row Deep Groove Ball Bearings 207-KPPB3

The 207-KPPB3 is a single-row deep groove ball bearing with a 35mm bore and 72mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 6182 lbf and operates smoothly at speeds reaching 10,000 RPM.

Its open design simplifies maintenance, while the chrome steel cage enhances durability. Suitable for temperatures between -30°C and 120°C, it’s built for consistent performance.

This model is interchangeable with SKF bearings, offering a reliable replacement option. Perfect for machinery like pumps or electric motors where radial loads are common.

Weighing 0.31kg, it balances strength and lightness. Compliant with RoHS and REACH standards, ensuring safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 207-KPPB3
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 6182 lbf
  • Static Radial Load 4946 lbf
  • Max Speed 10000 rpm
  • Weight 0.31 kg
Single Row Deep Groove Ball Bearings 207-KPPB3 dimension drawing
Download DWG Download PDF

Features

Performance Features of 207-KPPB3 Bearing

207-KPPB3 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 6182 lbf, making it suitable for various industrial applications.
The open design allows for easy lubrication, ensuring smooth operation over time.
With a maximum speed of 10,000 rpm, it delivers reliable performance in high-speed conditions.

Application

Industrial Uses of 207-KPPB3 Bearing
207-KPPB3 Bearing works well in machine tools and conveyor systems, handling radial loads with ease. Its open design simplifies maintenance in dusty or high-temperature environments.

Where Is 207-KPPB3 Bearing Used?
You’ll often spot 207-KPPB3 Bearing in automotive gearboxes and electric motors, where its durable chrome steel construction keeps things running smoothly. The metric sizing fits neatly into European and Asian vehicle designs.

Perfect Fit for Automation: 207-KPPB3 Bearing
In robotic arms and automated assembly lines, 207-KPPB3 Bearing offers reliable performance thanks to its balanced radial load capacity. The ABEC 1 tolerance ensures consistent operation without unnecessary complexity.

Medical vs Industrial: Where 207-KPPB3 Bearing Excels
While 207-KPPB3 Bearing handles industrial machinery like pumps and compressors, it’s also suited for medical centrifuges where quiet operation matters. The chrome steel cage resists wear in both environments.

Light-Duty vs Heavy-Duty: Best Uses for 207-KPPB3 Bearing
For light-duty applications like office printers or home appliances, 207-KPPB3 Bearing provides smooth rotation. In heavier settings such as agricultural equipment, its static load capacity of 4946 lbf ensures longevity.
