Single Row Deep Groove Ball Bearings 206SZZST

Single Row Deep Groove Ball Bearings 206SZZST

The 206SZZST is a single-row deep groove ball bearing with a 30mm bore and 62mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 4699 lbf and operates smoothly at speeds up to 12,000 RPM.

Its shielded design keeps out dust and debris, while the chrome steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or small machinery where radial loads are common.

Weighing just 0.21kg, it’s lightweight yet robust. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 206SZZST
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 16 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 4699 lbf
  • Static Radial Load 3664 lbf
  • Max Speed 12000 rpm
  • Weight 0.21 kg
  • price（$） 32.886
Single Row Deep Groove Ball Bearings 206SZZST dimension drawing
Download DWG Download PDF

Features

Why Choose 206SZZST Bearing for Precision Tasks?

206SZZST Bearing features a shielded design, protecting against contaminants while maintaining smooth operation.
Its chrome steel construction ensures durability and resistance to wear in radial load applications.

With a dynamic radial load capacity of 4699 lbf, it handles demanding tasks with ease.
The ABEC 1 tolerance class guarantees consistent performance for precision requirements.

Operating within a temperature range of -30°C to 120°C, it adapts to various environments.
Its maximum speed of 12,000 rpm makes it suitable for high-speed applications.

The single-row deep groove design ensures reliable performance with minimal maintenance.
206SZZST Bearing’s compact size (30 mm×62 mm×16 mm) allows for easy integration into different systems.

Application

Industrial Uses of 206SZZST Bearing
206SZZST Bearing is commonly used in conveyor systems, where its shielded design helps keep out dust and debris. The chrome steel construction ensures it can handle continuous radial loads without wearing out quickly.

Where Is 206SZZST Bearing Used?
You’ll often find 206SZZST Bearing in electric motors, thanks to its balanced performance at high speeds. Its ABEC 1 tolerance makes it reliable for general industrial applications where precision isn’t overly critical.

Perfect Fit for Automation: 206SZZST Bearing
In robotic arms, 206SZZST Bearing provides smooth rotation for precise movements. The shielded seals also help maintain lubrication, reducing maintenance needs in automated systems.

Automotive vs Industrial: Applications of 206SZZST Bearing
While 206SZZST Bearing works well in car alternators, it’s equally at home in industrial pumps. Its temperature range of -30°C to 120°C covers most operating conditions in both fields.

Key Fields for 206SZZST Bearing
206SZZST Bearing is a go-to choice for household appliances like washing machines, where quiet operation matters. The metric sizing ensures easy replacement in European-designed equipment.
