Single Row Deep Groove Ball Bearings 206SFF

Single Row Deep Groove Ball Bearings 206SFF

The 206SFF is a single-row deep groove ball bearing with a 30mm bore and 62mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 4699 lbf and spins smoothly at speeds up to 12,000 RPM.

Its open design allows for easy lubrication, while the chrome steel cage enhances durability. The bearing operates well in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing just 0.21kg, it’s lightweight yet robust. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 206SFF
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 16 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 4699 lbf
  • Static Radial Load 3664 lbf
  • Max Speed 12000 rpm
  • Weight 0.21 kg
  • price（$） 3.582
Single Row Deep Groove Ball Bearings 206SFF dimension drawing
Download DWG Download PDF

Features

Performance Features of 206SFF Bearing

206SFF Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 4699 lbf, making it suitable for various applications.
The open design allows for easy lubrication, ensuring smooth operation over time.
With a maximum speed of 12,000 rpm, it delivers reliable performance in demanding conditions.

Application

Industrial Uses of 206SFF Bearing
206SFF Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures reliable performance. The open design allows for easy lubrication, extending its service life in demanding conditions.

Where Is 206SFF Bearing Used?
In automotive applications, 206SFF Bearing fits well in alternators and wheel hubs, providing smooth rotation under radial loads. Its chrome steel construction offers durability, making it suitable for long-term use in vehicles.

Perfect Fit for Automation: 206SFF Bearing
For automation systems, 206SFF Bearing works efficiently in conveyor belts and robotic arms, where precision and low friction are key. The ABEC 1 tolerance ensures consistent performance in high-speed operations.

Medical vs Industrial: Where 206SFF Bearing Excels
In medical devices like centrifuges, 206SFF Bearing delivers quiet and stable operation. Its chrome steel cage enhances durability, while the open design simplifies maintenance in industrial settings.

Essential Roles of 206SFF Bearing
206SFF Bearing is a go-to choice for household appliances like washing machines, thanks to its balanced load handling. The metric sizing makes it versatile for various applications across different regions.
