Single Row Deep Groove Ball Bearings 16014

Single Row Deep Groove Ball Bearings 16014

The 16014 is a single-row deep groove ball bearing with a 70mm bore and 110mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 6025 lbf and operates smoothly at speeds up to 5000 RPM.

Its open design simplifies lubrication, while the stainless steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. It’s well-suited for radial load applications like electric motors or small machinery.

Weighing 430g, it’s a compact yet robust choice. Compliant with RoHS and REACH standards, it’s safe for various industrial uses.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 16014
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No CN
  • Bore Dia 70 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 13 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Lubrication Required
  • REACH Compliant
  • Temperature Range -30° to 110 °C
  • Dynamic Radial Load 6025 lbf
  • Static Radial Load 5305 lbf
  • Max Speed 5000 rpm
  • Weight 430 g
  • price（$） 19.08
Single Row Deep Groove Ball Bearings 16014 dimension drawing
Download DWG Download PDF

Features

Performance Features of 16014 Bearing

16014 Bearing is built with chrome steel rings and balls, offering strong radial load support up to 6025 lbf.

Its single-row deep groove design ensures smooth operation, making it suitable for various applications.

The stainless steel cage maintains ball alignment, reducing friction and extending the bearing’s life.

With a maximum speed of 5,000 rpm, it balances performance and durability in demanding conditions.

Application

Industrial Uses of 16014 Bearing
16014 Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures smooth operation. The open design allows for easy lubrication, extending its service life in demanding environments.

What Makes 16014 Bearing a Preferred Choice?
In automotive applications, 16014 Bearing fits well in components such as alternators and water pumps, thanks to its durable chrome steel construction. Its metric sizing makes it a versatile option for various vehicle models.

Perfect Fit for Automation: 16014 Bearing
For automation systems, 16014 Bearing works reliably in conveyor belts and robotic arms, where precision and low maintenance are key. The stainless steel cage adds to its longevity in continuous-use scenarios.

Medical vs Industrial: Where 16014 Bearing Excels
While 16014 Bearing performs well in industrial gearboxes, it’s also suitable for medical devices like centrifuges, where consistent radial load handling is essential. The ABEC-1 tolerance ensures dependable performance in both fields.
