Single Row Deep Groove Ball Bearings 16005

Single Row Deep Groove Ball Bearings 16005

The 16005 is a compact single-row deep groove ball bearing, measuring 25mm by 47mm by 8mm, crafted from sturdy chrome steel. It handles radial loads up to 1574 lbf and spins smoothly at speeds up to 11000 RPM.

Its open design allows for easy lubrication, while the stainless steel cage ensures durability. The bearing operates reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. It’s well-suited for applications like electric motors or small machinery where radial loads are common.

Weighing just 60g, it’s lightweight yet robust. Compliant with RoHS and REACH standards, it’s a safe and reliable option for various uses.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 16005
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No CN
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 47 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 8 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Lubrication Required
  • REACH Compliant
  • Temperature Range -30° to 110 °C
  • Dynamic Radial Load 1574 lbf
  • Static Radial Load 1034 lbf
  • Max Speed 11000 rpm
  • Weight 60 g
  • price（$） 3.798
Single Row Deep Groove Ball Bearings 16005 dimension drawing
Download DWG Download PDF

Features

Why Choose 16005 Bearing for Precision Tasks?

16005 Bearing features a single row deep groove design, ideal for handling radial loads with precision.
Its chrome steel rings and balls provide durability, while the stainless steel cage ensures smooth operation.

With a dynamic radial load capacity of 1574 lbf, it performs reliably in various applications.
The ABEC-1 tolerance class guarantees consistent performance, suitable for standard precision needs.

Operating within a temperature range of -30° to 110°C, 16005 Bearing adapts to diverse environments.
Its open design simplifies lubrication, maintaining efficiency over time.

Application

Common Applications of 16005 Bearing
16005 Bearing is widely used in industrial equipment like small electric motors and pumps, where its compact design and radial load capacity are beneficial. The open seal allows for easy lubrication, extending its service life in dusty environments.

In automotive applications, 16005 Bearing fits well in components such as alternators and cooling fans, providing smooth rotation under moderate loads. Its metric sizing ensures compatibility with various vehicle models.

For home appliances, 16005 Bearing is a reliable choice for items like washing machines and blenders, thanks to its durable chrome steel construction. The stainless steel cage adds extra resistance to wear in daily use.

Automation systems often incorporate 16005 Bearing in conveyor belts and small robotic arms, where precision and reliability are key. Its ABEC-1 tolerance ensures consistent performance in repetitive tasks.

Medical devices like dental drills and lab equipment benefit from 16005 Bearing’s quiet operation and low maintenance needs. The temperature range makes it suitable for sterilisation processes.
