Single Row Deep Groove Ball Bearings 16004/C3W64

Single Row Deep Groove Ball Bearings 16004/C3W64

The 16004/C3W64 is a single-row deep groove ball bearing with a 20mm bore and 42mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 1416 lbf and spins smoothly at speeds up to 13,000 RPM.

Its open design and solid oil lubrication ensure low maintenance, while the chrome steel cage offers durability. The bearing operates well in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or small machinery where radial loads are common.

Weighing just 50g, it’s lightweight yet robust. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 16004/C3W64
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 20 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 42 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 8 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Lubrication Soild Oil
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 1416 lbf
  • Static Radial Load 854 lbf
  • Max Speed 13000 rpm
  • Weight 50 g
  • price（$） 7.929
Single Row Deep Groove Ball Bearings 16004/C3W64 dimension drawing
Download DWG Download PDF

Features

Why Choose 16004/C3W64 Bearing for Precision Tasks?

16004/C3W64 Bearing features a single row deep groove design, ideal for handling radial loads with precision.
Its chrome steel construction ensures durability and smooth operation under various conditions.

The C3 radial clearance allows for thermal expansion, making it suitable for high-speed applications.
With a maximum speed of 13,000 rpm, it delivers reliable performance without compromising efficiency.

Solid oil lubrication reduces maintenance needs while extending the bearing’s service life.
Its temperature range of -30°C to 120°C ensures consistent performance in diverse environments.

Application

Common Applications of 16004/C3W64 Bearing
16004/C3W64 Bearing is widely used in industrial machinery, such as small electric motors and pumps, where its radial load capacity and solid oil lubrication ensure long service life. The open design allows for easy inspection and maintenance in dusty environments.

In automotive applications, 16004/C3W64 Bearing fits well in components like alternators and cooling fans, providing smooth rotation under moderate loads. Its metric sizing makes it a versatile choice for various vehicle models.

For home appliances, 16004/C3W64 Bearing works efficiently in devices like washing machines and power tools, where reliability and quiet operation are key. The chrome steel construction ensures durability even with frequent use.

Automation systems benefit from 16004/C3W64 Bearing in robotic arms and conveyor belts, where precise movement and low friction are essential. The C3 clearance helps accommodate thermal expansion in high-speed operations.

Medical equipment like small centrifuges often use 16004/C3W64 Bearing for its consistent performance and compliance with RoHS standards. The solid oil lubrication reduces contamination risks in sensitive environments.
