Single Row Cylindrical Roller Thrust Bearings 811/600 M/HB1

Single Row Cylindrical Roller Thrust Bearings 811/600 M/HB1

The 811/600 M/HB1 is a single-row cylindrical roller thrust bearing with a 600mm bore and 710mm outer diameter, built to handle heavy loads. Made from durable chrome steel, it supports dynamic radial loads up to 405,000 lbf and static loads up to 2,610,000 lbf.

Its machined brass cage ensures smooth operation at speeds up to 500 RPM, even in temperatures from -30°C to 110°C. The robust design includes precise tolerances for reliable performance in demanding conditions.

This bearing is interchangeable with SKF models, making it a practical choice for replacements. Ideal for heavy machinery like industrial presses or large gearboxes where high thrust loads are common.

Weighing 64kg, it’s built for stability and long-term use. Compliant with RoHS and REACH standards for safe and environmentally friendly operation.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 811/600 M/HB1
  • size 600 mm x 710 mm x 85 mm
  • Brand TFL
  • Interchangeable brand SKF
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • Bearing Type Roller
  • For Load Direction Thrust
  • Number of Rows 1
  • Bore Dia 600 mm
  • Bore Dia Tolerance -0.050mm to 0
  • Outer Dia 710 mm
  • Outer Dia Tolerance -0.075mm to 0
  • Width 85 mm
  • Height Tolerance -0.60mm to +0.06mm
  • Outside Diameter Shaft Washer 705 mm
  • Bore Diameter Housing Washer 605 mm
  • Height Shaft Washer 25.5 mm
  • Chamfer Dimension Housing Washer r1,2 (min.) 3 mm
  • Washer Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Machined brass cage
  • Dynamic Radial Load 405000 lbf
  • Static Radial Load 2610000 lbf
  • Max Speed 500 rpm
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 64 kg
  • Shaft Washer IW-811/600/HB3
  • Housing Washer OW-811/600/HB2
Single Row Cylindrical Roller Thrust Bearings 811/600 M/HB1 dimension drawing
Download DWG Download PDF

Features

Performance Features of 811/600 M/HB1 Bearing

811/600 M/HB1 Bearing is built with chrome steel washers and rollers, offering robust resistance to heavy thrust loads.
Its dynamic radial load capacity reaches 405,000 lbf, making it suitable for high-demand industrial applications.

The machined brass cage ensures precise roller alignment, enhancing durability and reducing operational wear.
With a maximum speed of 500 rpm, it delivers reliable performance under substantial pressure.

811/600 M/HB1 Bearing operates efficiently in temperatures ranging from -30° to 110°C.
Its chrome steel construction provides excellent resistance to wear, even in challenging environments.

The bearing’s design simplifies installation, saving time and effort during setup.
Its large dimensions (600 mm x 710 mm x 85 mm) make it ideal for heavy machinery and industrial equipment.

Application

Industrial Uses of 811/600 M/HB1 Bearing
811/600 M/HB1 Bearing is commonly used in heavy machinery like hydraulic presses and large gearboxes, where its cylindrical roller design handles high thrust loads efficiently. The machined brass cage ensures smooth operation even under demanding conditions.

Where Is 811/600 M/HB1 Bearing Used?
You’ll find 811/600 M/HB1 Bearing in wind turbine systems, supporting the main shaft where reliability is key. Its chrome steel construction and precise tolerances make it ideal for such high-stress environments.

Built for Heavy-Duty Use: 811/600 M/HB1 Bearing
811/600 M/HB1 Bearing excels in mining equipment, particularly in conveyor systems that require robust axial load support. The large bore diameter and durable materials ensure long service life in tough applications.

Automotive vs Aerospace: Applications of 811/600 M/HB1 Bearing
In automotive testing rigs, 811/600 M/HB1 Bearing handles extreme loads during durability tests. While not typically used in aerospace, its precision makes it suitable for ground support equipment.

Practical Applications of 811/600 M/HB1 Bearing
811/600 M/HB1 Bearing is a go-to choice for steel mills, where it supports rolling mill stands under intense pressure. The metric sizing and interchangeable design with SKF models simplify maintenance and replacements.
