Single Row Cylindrical Roller Bearings With Inner Ring NUP 2313 ECP

Single Row Cylindrical Roller Bearings With Inner Ring NUP 2313 ECP

The NUP 2313 ECP is a single row cylindrical roller bearing with a 65mm bore and 140mm outer diameter, crafted from sturdy chrome steel. It handles combined loads up to 64125 lbf and runs smoothly at speeds up to 6000 RPM.

Its open design allows for easy lubrication with grease or oil, while the PA66 cage ensures reliable performance. The bearing operates well in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for heavy-duty applications like industrial machinery or gearboxes where combined loads are common.

Weighing 3.44kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number NUP 2313 ECP
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.15mm to 0
  • Outer Dia 140 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 48 mm
  • Width Tolerance -0.15mm to 0
  • Shoulder Dia Of Inner Ring 90.5 mm
  • Chamfer Dimension r1,2(min.) 2.1 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • For Load Direction Combined
  • Construction Single Row
  • Inner Ring Type With Inner Ring
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material PA66 cage, roller centred
  • Dynamic Radial Load 64125 lbf
  • Static Radial Load 65250 lbf
  • Lubrication Grease, Oil
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 6000 rpm
  • Weight 3.44 kg
  • Shoulder Dia Of Outer Ring 117.4 mm
  • Raceway Diameter Of Inner Ring 82.5 mm
  • Chamfer Dimension Of Loose Flange Ring(r3,4)(min.) 2.1 mm
Single Row Cylindrical Roller Bearings With Inner Ring NUP 2313 ECP dimension drawing
Download DWG Download PDF

Features

How Does NUP 2313 ECP Bearing Handle Combined Loads?

NUP 2313 ECP Bearing features chrome steel rings and rollers, providing strong resistance to both radial and axial loads.
Its dynamic radial load capacity reaches 64125 lbf, ensuring reliable performance in demanding applications.
The PA66 cage keeps the rollers centred, reducing wear and extending service life.
With a maximum speed of 6000 rpm, it balances durability and efficiency.

Application

Industrial Uses of NUP 2313 ECP Bearing
NUP 2313 ECP Bearing is commonly used in heavy machinery like industrial gearboxes and large conveyor systems, where its cylindrical roller design handles both radial and axial loads efficiently. The chrome steel construction ensures durability even in demanding environments.

What Makes NUP 2313 ECP Bearing a Preferred Choice?
In automotive applications, NUP 2313 ECP Bearing supports components such as transmissions and differentials, providing reliable performance under high loads. Its PA66 cage design reduces friction, making it suitable for high-speed operations.

Perfect Fit for Automation: NUP 2313 ECP Bearing
NUP 2313 ECP Bearing is ideal for robotic arms and automated production lines, where precision and load capacity are critical. The open seal type allows for easy lubrication, ensuring long service life.

Medical vs Industrial: Where NUP 2313 ECP Bearing Excels
While NUP 2313 ECP Bearing is robust enough for industrial presses, its precision also makes it suitable for medical imaging devices requiring smooth rotation. The temperature range of -30° to 110°C adds to its versatility.

Key Fields for NUP 2313 ECP Bearing
NUP 2313 ECP Bearing is often found in wind turbines and mining equipment, where its high dynamic radial load capacity is essential. The metric sizing ensures compatibility with a wide range of machinery.
