Single Row Cylindrical Roller Bearings With Inner Ring NUP 2213 ECP

The NUP 2213 ECP is a single-row cylindrical roller bearing with a 65mm bore and 120mm outer diameter, crafted from durable chrome steel. It handles combined loads up to 38250 lbf and spins smoothly at speeds up to 7000 RPM.

Its open design allows easy lubrication with grease or oil, while the PA66 cage ensures reliable performance. The bearing operates well in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like gearboxes or industrial machinery where combined loads are common.

Weighing 1.46kg, it’s sturdy yet manageable for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number NUP 2213 ECP
Brand TFL
Interchangeable SKF
Bore Dia 65 mm
Bore Dia Tolerance -0.15mm to 0
Outer Dia 120 mm
Outer Dia Tolerance -0.015mm to 0
Width 31 mm
Width Tolerance -0.15mm to 0
Shoulder Dia Of Inner Ring 84.4 mm
Chamfer Dimension r1,2(min.) 1.5 mm
System of Measurement Metric
Roller Bearing Type Cylindrical
For Load Direction Combined
Construction Single Row
Inner Ring Type With Inner Ring
Seal Type Open
Ring Material Chrome Steel
Roller Material Chrome Steel
Cage Material PA66 cage, roller centred
Dynamic Radial Load 38250 lbf
Static Radial Load 40500 lbf
Lubrication Grease, Oil
Temperature Range -30° to 110 °C
RoHS Compliant
REACH Compliant
Max Speed 7000 rpm
Weight 1.46 kg
Shoulder Dia Of Outer Ring 103.2 mm
Raceway Diameter Of Inner Ring 78.5 mm
Chamfer Dimension Of Loose Flange Ring(r3,4)(min.) 1.5 mm

Single Row Cylindrical Roller Bearings With Inner Ring NUP 2213 ECP dimension drawing

Download DWG Download PDF

Features

Why Choose NUP 2213 ECP Bearing for Precision Tasks?

NUP 2213 ECP Bearing features a chrome steel construction, ensuring high resistance to wear and tear.
Its dynamic radial load capacity of 38,250 lbf makes it suitable for heavy-duty applications.

The PA66 cage keeps the rollers centred, enhancing stability and reducing friction.
With a maximum speed of 7,000 rpm, it delivers reliable performance in various conditions.

NUP 2213 ECP Bearing operates efficiently in temperatures ranging from -30° to 110°C.
Its open design allows for easy lubrication, extending maintenance intervals.

Application

Industrial Uses of NUP 2213 ECP Bearing
NUP 2213 ECP Bearing is commonly used in heavy machinery like gearboxes and industrial pumps, where its cylindrical roller design handles both radial and axial loads efficiently. The chrome steel construction ensures durability even in demanding environments.

Where Is NUP 2213 ECP Bearing Used?
You’ll often find NUP 2213 ECP Bearing in automotive transmissions, where its high-speed capability and combined load support keep things running smoothly. The open design allows for easy lubrication, extending its service life.

Built for Heavy-Duty Use: NUP 2213 ECP Bearing
NUP 2213 ECP Bearing excels in conveyor systems, thanks to its robust PA66 cage that reduces friction and wear. Its metric sizing makes it a versatile choice for European and Asian equipment.

Automotive vs Industrial: Applications of NUP 2213 ECP Bearing
In automotive applications, NUP 2213 ECP Bearing supports drivetrain components, while in industrial settings, it’s ideal for heavy-load machinery. The temperature range of -30° to 110°C ensures reliability in various conditions.

Perfect Fit for Automation: NUP 2213 ECP Bearing
NUP 2213 ECP Bearing is a great match for robotic arms and automated production lines, where precision and load capacity are key. The grease or oil lubrication options provide flexibility for different operational needs.
