Drawn Cup Needle Roller Bearings SCE3410

Drawn Cup Needle Roller Bearings SCE3410

The SCE3410 is a drawn cup needle roller bearing with a 2.125″ bore and 2.5″ outer diameter, crafted from sturdy steel. It handles radial loads up to 6969 lbf and operates smoothly at speeds up to 4900 RPM.
Its open-end design allows for easy lubrication, while the press-fit shaft mount ensures a secure installation. The bearing performs reliably in temperatures ranging from -20°C to 110°C.
This model is interchangeable with INA bearings, making it a practical choice for replacements. Ideal for applications like automotive components or industrial machinery where radial loads are common.
Weighing in at a compact size of 0.625″ width, it’s both durable and easy to handle. Compliant with RoHS standards for safe and environmentally friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number SCE3410
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 2.125"
  • Bore Dia Tolerance Refer to note on the right drawing
  • Outer Dia 2.5"
  • Outer Dia Tolerance Not Rated
  • Width 0.625"
  • Width Tolerance -0.01" to 0"
  • System of Measurement Inch
  • Bearing Type Roller
  • Roller Bearing Type Needle
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Series Open End
  • Ring Material Steel
  • Ball Material Steel
  • Cage Material Steel
  • Dynamic Radial Load 6969 lbf
  • Static Radial Load 12814 lbf
  • Lubrication Required
  • Shaft Mount Type Press Fit
  • Temperature Range -20 to 110 °C
  • RoHS Compliant
  • Max Speed 4900 rpm
  • Weight 72 g
Drawn Cup Needle Roller Bearings SCE3410 dimension drawing
Download DWG Download PDF

Features

How Does SCE3410 Bearing Handle Heavy Loads?
SCE3410 Bearing is built with steel rings and rollers, offering strong resistance to heavy radial loads.
Its dynamic radial load capacity reaches 6969 lbf, making it reliable for demanding applications.
The open-end design allows for easy press-fit installation, saving time and effort.
With a maximum speed of 4900 rpm, it balances durability and efficiency in various conditions.

Application

Industrial Uses of SCE3410 Bearing
SCE3410 Bearing is commonly used in industrial gearboxes, where its compact design helps save space while handling high radial loads. The steel construction ensures durability in demanding environments like conveyor systems.
Where Is SCE3410 Bearing Used?
You’ll often find SCE3410 Bearing in automotive transmissions, providing smooth operation under heavy loads. Its press-fit design makes installation straightforward, ideal for assembly lines.
Built for Heavy-Duty Use: SCE3410 Bearing
SCE3410 Bearing excels in construction equipment, such as hydraulic pumps, thanks to its robust steel rollers. The open-end design allows for easy lubrication, extending service life.
Automotive vs Industrial: Applications of SCE3410 Bearing
In automotive steering systems, SCE3410 Bearing offers reliable performance, while in industrial machinery, it handles high-speed rotations. Its inch sizing ensures compatibility with various equipment.
Perfect Fit for Automation: SCE3410 Bearing
SCE3410 Bearing works well in robotic arms, where precision and load capacity are key. The steel cage provides stability, making it suitable for repetitive movements.
