Single Row Cylindrical Roller Bearings With Inner Ring NU 318 ECM

Single Row Cylindrical Roller Bearings With Inner Ring NU 318 ECM

The NU 318 ECM is a single-row cylindrical roller bearing with a 90mm bore and 190mm outer diameter, built from sturdy chrome steel. It handles combined loads up to 82125 lbf and runs smoothly at speeds up to 4000 RPM.

Its brass cage keeps rollers centred for even load distribution, while the open design allows easy lubrication with grease or oil. The bearing operates well in temperatures from -30°C to 110°C.

With a 43mm width and chamfered edges, it fits snugly in tight spaces. Ideal for heavy-duty applications like gearboxes or industrial machinery where radial and axial loads are present.

Weighing 6.03kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s a reliable choice for replacements, interchangeable with SKF bearings.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number NU 318 ECM
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 90 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 190 mm
  • Outer Dia Tolerance -0.03mm to 0
  • Width 43 mm
  • Width Tolerance -0.20mm to 0
  • Chamfer Dimension r1,2(min.) 3 mm
  • Chamfer Dimension r3,4(min.) 3 mm
  • Permissible Axial Displacement(max.) 2.5 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • For Load Direction Combined
  • Construction Single Row
  • Inner Ring Type With Inner Ring
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Brass cage, roller centred
  • Dynamic Radial Load 82125 lbf
  • Static Radial Load 81000 lbf
  • Lubrication Grease, Oil
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 4000 rpm
  • Weight 6.03 kg
  • Shoulder Dia Of Outer Ring 160.3 mm
  • Raceway Diameter Of Inner Ring 113.5 mm
Single Row Cylindrical Roller Bearings With Inner Ring NU 318 ECM dimension drawing
Download DWG Download PDF

Features

How Does NU 318 ECM Bearing Handle Combined Loads?

NU 318 ECM Bearing features a chrome steel construction, providing excellent resistance to both radial and axial loads.
Its dynamic radial load capacity reaches 82,125 lbf, ensuring reliable performance in heavy-duty applications.
The brass cage keeps the rollers centred, reducing friction and extending service life.
With a maximum speed of 4,000 rpm, it offers a balance of durability and efficiency.

Application

Industrial Uses of NU 318 ECM Bearing
NU 318 ECM Bearing is commonly used in heavy machinery like gearboxes and industrial pumps, where its cylindrical roller design handles combined loads efficiently. The brass cage ensures smooth operation even at high speeds up to 4000 rpm.

What Makes NU 318 ECM Bearing a Preferred Choice?
In automotive applications, NU 318 ECM Bearing fits well in transmission systems due to its robust chrome steel construction. Its open design allows for easy lubrication, extending service life in demanding conditions.

Built for Heavy-Duty Use: NU 318 ECM Bearing
For conveyor systems, NU 318 ECM Bearing’s high dynamic radial load capacity makes it reliable for continuous operation. The metric dimensions ensure compatibility with a wide range of industrial equipment.

Automotive vs Aerospace: Applications of NU 318 ECM Bearing
While NU 318 ECM Bearing excels in car transmissions, its precision also suits aerospace components requiring consistent performance. The temperature range of -30° to 110°C adds versatility across environments.

Perfect Fit for Automation: NU 318 ECM Bearing
In robotic arms, NU 318 ECM Bearing’s low friction and high-speed capability enhance movement accuracy. The brass cage reduces wear, making it ideal for repetitive tasks in automated systems.
