Single Row Cylindrical Roller Bearings With Inner Ring NU 305 ECP

Single Row Cylindrical Roller Bearings With Inner Ring NU 305 ECP

The NU 305 ECP is a single row cylindrical roller bearing with a 25mm bore and 62mm outer diameter, crafted from durable chrome steel. It handles combined loads up to 10462 lbf and reaches speeds of 15000 RPM.

Its open design allows for easy lubrication with grease or oil, while the PA66 cage ensures smooth operation. The bearing performs reliably in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or pumps where radial and axial loads are present.

Weighing just 0.23kg, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number NU 305 ECP
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.12mm to 0
  • Chamfer Dimension r1,2(min.) 1.1 mm
  • Chamfer Dimension r3,4(min.) 1.1 mm
  • Permissible Axial Displacement(max.) 1.3 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • For Load Direction Combined
  • Construction Single Row
  • Inner Ring Type With Inner Ring
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material PA66 cage, roller centred
  • Dynamic Radial Load 10462 lbf
  • Static Radial Load 8212 lbf
  • Lubrication Grease, Oil
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 15000 rpm
  • Weight 0.23 kg
  • Shoulder Dia Of Outer Ring 50.25 mm
  • Raceway Diameter Of Inner Ring 34 mm
Single Row Cylindrical Roller Bearings With Inner Ring NU 305 ECP dimension drawing
Download DWG Download PDF

Features

Why Choose NU 305 ECP Bearing for Precision Tasks?

NU 305 ECP Bearing features a single-row cylindrical roller design, ideal for handling combined loads with precision.
Its chrome steel construction ensures durability and resistance to wear in demanding applications.

The PA66 cage keeps rollers centred, enhancing stability and reducing friction during operation.
With a dynamic radial load capacity of 10462 lbf, it performs reliably under heavy loads.

NU 305 ECP Bearing operates smoothly at speeds up to 15000 rpm, making it suitable for high-speed machinery.
Its open design allows for easy lubrication with grease or oil, ensuring long service life.

The temperature range of -30° to 110 °C ensures consistent performance in various environments.
This bearing is interchangeable with SKF models, offering flexibility in replacement and maintenance.

Application

Industrial Uses of NU 305 ECP Bearing
NU 305 ECP Bearing is commonly used in industrial machinery like gearboxes and pumps, where its cylindrical roller design handles combined loads efficiently. The chrome steel construction ensures durability in demanding environments.

What Makes NU 305 ECP Bearing a Preferred Choice?
In automotive applications, NU 305 ECP Bearing supports components such as transmissions and differentials, offering reliable performance under high-speed conditions. Its open design allows for easy lubrication, extending service life.

Perfect Fit for Automation: NU 305 ECP Bearing
NU 305 ECP Bearing works well in robotic arms and automated production lines, thanks to its high-speed capability and precise radial load handling. The PA66 cage reduces friction, enhancing smooth operation.

Medical vs Industrial: Where NU 305 ECP Bearing Excels
NU 305 ECP Bearing is ideal for industrial equipment like conveyors, while its precision also suits medical devices requiring consistent motion control. The temperature range ensures reliability in various settings.

Essential Roles of NU 305 ECP Bearing
In consumer electronics, NU 305 ECP Bearing can be found in printers and power tools, where its compact size and load capacity are advantageous. The grease lubrication option simplifies maintenance for home users.
