Single Row Cylindrical Roller Bearings With Inner Ring NU 226 ECJ

Single Row Cylindrical Roller Bearings With Inner Ring NU 226 ECJ

The NU 226 ECJ is a single row cylindrical roller bearing with a 130mm bore and 230mm outer diameter, crafted from durable chrome steel. It handles combined loads up to 93375 lbf and operates smoothly at speeds up to 3000 RPM.

Its open design allows for easy lubrication with grease or oil, while the steel cage ensures stable performance. The bearing works well in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a reliable choice for replacements. Ideal for heavy-duty applications like industrial machinery or gearboxes where radial and axial loads are present.

Weighing 6.28kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe use.

The chamfered edges (3mm) and permissible axial displacement (2.1mm) add to its versatility. Suitable for scenarios requiring precise alignment and durability.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number NU 226 ECJ
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 130 mm
  • Bore Dia Tolerance -0.025mm to 0
  • Outer Dia 230 mm
  • Outer Dia Tolerance -0.03mm to 0
  • Width 40 mm
  • Width Tolerance -0.25mm to 0
  • Chamfer Dimension r1,2(min.) 3 mm
  • Chamfer Dimension r3,4(min.) 3 mm
  • Permissible Axial Displacement(max.) 2.1 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • For Load Direction Combined
  • Construction Single Row
  • Inner Ring Type With Inner Ring
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel cage, roller centred
  • Dynamic Radial Load 93375 lbf
  • Static Radial Load 102375 lbf
  • Lubrication Grease, Oil
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 3000 rpm
  • Weight 6.28 kg
  • Shoulder Dia Of Outer Ring 200.3 mm
  • Raceway Diameter Of Inner Ring 153.5 mm
Single Row Cylindrical Roller Bearings With Inner Ring NU 226 ECJ dimension drawing
Download DWG Download PDF

Features

Performance Features of NU 226 ECJ Bearing

NU 226 ECJ Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 93,375 lbf, ensuring reliable performance in heavy-duty applications.

The steel cage keeps the rollers centred, reducing friction and extending service life.
With a maximum speed of 3,000 rpm, it balances durability and efficiency in demanding conditions.

NU 226 ECJ Bearing operates smoothly in temperatures ranging from -30° to 110°C.
Its open design allows for easy lubrication with grease or oil, reducing maintenance needs.

The precise chamfer dimensions of 3 mm ensure easy installation and alignment.
This bearing is interchangeable with SKF models, providing flexibility for various applications.

Application

Industrial Uses of NU 226 ECJ Bearing
NU 226 ECJ Bearing is commonly used in heavy machinery like industrial gearboxes and large electric motors, where its cylindrical roller design handles high radial loads efficiently. The open seal type allows for easy lubrication, making it suitable for continuous operation environments.

In automotive applications, NU 226 ECJ Bearing supports components such as wheel hubs and transmissions, providing reliable performance under combined loads. Its chrome steel construction ensures durability even in demanding driving conditions.

For automation systems, NU 226 ECJ Bearing is ideal for robotic arms and conveyor belts, thanks to its high-speed capability and precise axial displacement tolerance. The steel cage design further enhances its stability in dynamic movements.

NU 226 ECJ Bearing also finds use in wind turbines, where its robust design withstands variable loads and harsh weather conditions. The metric sizing ensures compatibility with a wide range of European and Asian equipment standards.
