Single Row Cylindrical Roller Bearings With Inner Ring NU 2210 ECPH

Single Row Cylindrical Roller Bearings With Inner Ring NU 2210 ECPH

The NU 2210 ECPH is a single row cylindrical roller bearing with a 50mm bore and 90mm outer diameter, crafted from durable chrome steel. Its compact width of 23mm makes it suitable for space-conscious applications.

This bearing handles combined loads with ease, supporting dynamic radial loads up to 20250 lbf. It operates smoothly at speeds up to 9000 RPM and works in temperatures from -30°C to 110°C.

Featuring a PEEK cage for reduced friction, it offers reliable performance with either grease or oil lubrication. The open design allows for easy maintenance and inspection.

Ideal for industrial machinery, gearboxes, or pumps where radial and axial loads are present. Weighing 0.56kg, it’s a robust yet manageable component for various mechanical systems. Compliant with RoHS and REACH standards.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number NU 2210 ECPH
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 90 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 23 mm
  • Width Tolerance -0.12mm to 0
  • Chamfer Dimension r1,2(min.) 1.1 mm
  • Chamfer Dimension r3,4(min.) 1.1 mm
  • Permissible Axial Displacement(max.) 1.5 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • For Load Direction Combined
  • Construction Single Row
  • Inner Ring Type With Inner Ring
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material PEEK cage, roller centred
  • Dynamic Radial Load 20250 lbf
  • Static Radial Load 19800 lbf
  • Lubrication Grease, Oil
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 9000 rpm
  • Weight 0.56 kg
  • Shoulder Dia Of Outer Ring 77.58 mm
  • Raceway Diameter Of Inner Ring 59.5 mm
Single Row Cylindrical Roller Bearings With Inner Ring NU 2210 ECPH dimension drawing
Download DWG Download PDF

Features

How Does NU 2210 ECPH Bearing Handle Combined Loads?

NU 2210 ECPH Bearing is built with chrome steel rings and rollers, offering strong resistance to both radial and axial loads.
Its dynamic radial load capacity reaches 20250 lbf, ensuring reliable performance in demanding applications.
The PEEK cage keeps the rollers centred, reducing friction and extending service life.
With a maximum speed of 9,000 rpm, it balances durability and efficiency.

Application

Industrial Uses of NU 2210 ECPH Bearing
NU 2210 ECPH Bearing is commonly used in industrial machinery like gearboxes and pumps, where its cylindrical roller design handles combined loads efficiently. The PEEK cage ensures smooth operation even at high speeds up to 9000 rpm.

Where Is NU 2210 ECPH Bearing Used?
In automotive applications, NU 2210 ECPH Bearing fits well in transmissions and differentials, thanks to its chrome steel construction for durability. Its open design allows for easy lubrication, extending service life in demanding conditions.

Built for Heavy-Duty Use: NU 2210 ECPH Bearing
For automation systems, NU 2210 ECPH Bearing supports robotic arms and conveyor belts, offering reliable performance under continuous operation. The metric dimensions make it compatible with a wide range of European machinery.

Medical vs Industrial: Where NU 2210 ECPH Bearing Excels
In medical devices, NU 2210 ECPH Bearing provides precision in equipment like MRI scanners, where low noise is essential. The grease or oil lubrication options adapt to various operational needs.

Practical Applications of NU 2210 ECPH Bearing
NU 2210 ECPH Bearing is ideal for electric motors and fans, where its high-speed capability and load capacity ensure consistent performance. The temperature range of -30° to 110°C suits diverse environments.
