Single Row Cylindrical Roller Bearings With Inner Ring NU 217 ECM

Single Row Cylindrical Roller Bearings With Inner Ring NU 217 ECM

The NU 217 ECM is a single row cylindrical roller bearing with an 85mm bore and 150mm outer diameter, crafted from durable chrome steel. It handles combined loads up to 42750 lbf and operates smoothly at speeds up to 5000 RPM.

Its brass cage ensures stable roller movement, while the open design allows easy lubrication with grease or oil. The bearing performs well in temperatures ranging from -30°C to 110°C.

With a width of 28mm and chamfered edges, it fits snugly in tight spaces. This model is interchangeable with SKF bearings, making it a practical choice for replacements.

Ideal for heavy-duty applications like industrial gearboxes or machinery where radial and axial loads are present. Compliant with RoHS and REACH standards, it’s a reliable and safe option. Weighing 2.23kg, it’s sturdy yet manageable for its size.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number NU 217 ECM
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 85 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 150 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 28 mm
  • Width Tolerance -0.20mm to 0
  • Chamfer Dimension r1,2(min.) 2 mm
  • Chamfer Dimension r3,4(min.) 2 mm
  • Permissible Axial Displacement(max.) 1.5 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • For Load Direction Combined
  • Construction Single Row
  • Inner Ring Type With Inner Ring
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Brass cage, roller centred
  • Dynamic Radial Load 42750 lbf
  • Static Radial Load 45000 lbf
  • Lubrication Grease, Oil
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 5000 rpm
  • Weight 2.23 kg
  • Shoulder Dia Of Outer Ring 130.3 mm
  • Raceway Diameter Of Inner Ring 100.5 mm
Single Row Cylindrical Roller Bearings With Inner Ring NU 217 ECM dimension drawing
Download DWG Download PDF

Features

Performance Features of NU 217 ECM Bearing

NU 217 ECM Bearing is crafted with chrome steel rings and rollers, offering excellent resistance to combined loads.
Its dynamic radial load capacity reaches 42,750 lbf, ensuring reliable operation in demanding conditions.
The brass cage keeps the rollers centred, reducing friction and enhancing durability.
With a maximum speed of 5,000 rpm, it delivers consistent performance across various applications.

Application

Industrial Uses of NU 217 ECM Bearing
NU 217 ECM Bearing is commonly used in heavy machinery like conveyor systems and industrial gearboxes, where its cylindrical roller design handles combined loads efficiently. The brass cage ensures smooth operation even at high speeds.

Where Is NU 217 ECM Bearing Used?
You’ll often find NU 217 ECM Bearing in automotive transmissions, where its high radial load capacity supports smooth power transfer. Its open design allows for easy lubrication, extending service life in demanding conditions.

Built for Heavy-Duty Use: NU 217 ECM Bearing
NU 217 ECM Bearing excels in applications like printing presses, where precision and durability are key. The chrome steel construction provides reliable performance under continuous operation.

Automotive vs Aerospace: Applications of NU 217 ECM Bearing
In automotive systems, NU 217 ECM Bearing handles high radial loads in wheel hubs, while its aerospace use includes auxiliary gearboxes. The metric sizing ensures compatibility across industries.

Perfect Fit for Automation: NU 217 ECM Bearing
NU 217 ECM Bearing is ideal for robotic arms in automated production lines, offering low friction and high precision. The grease lubrication option reduces maintenance needs in continuous operation.
