Single Row Cylindrical Roller Bearings With Inner Ring NU 210 ECPH

Single Row Cylindrical Roller Bearings With Inner Ring NU 210 ECPH

The NU 210 ECPH is a single-row cylindrical roller bearing with a 50mm bore and 90mm outer diameter, crafted from durable chrome steel. It handles combined loads up to 16538 lbf and reaches speeds of 9000 RPM.

Its PEEK cage keeps rollers centred for smooth operation, while the open design allows easy lubrication with grease or oil. The bearing performs reliably in temperatures from -30°C to 110°C.

With a compact width of 20mm, it fits well in tight spaces. The chamfered edges (1.1mm) help with easy installation. Compliant with RoHS and REACH standards, it’s a safe choice for various applications.

Ideal for machinery like pumps or gearboxes where radial and axial loads are present. Its interchangeable design with SKF bearings makes it a practical replacement option. Weighing 0.47kg, it balances strength and portability.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number NU 210 ECPH
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 90 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 20 mm
  • Width Tolerance -0.12mm to 0
  • Chamfer Dimension r1,2(min.) 1.1 mm
  • Chamfer Dimension r3,4(min.) 1.1 mm
  • Permissible Axial Displacement(max.) 1.5 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • For Load Direction Combined
  • Construction Single Row
  • Inner Ring Type With Inner Ring
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material PEEK cage, roller centred
  • Dynamic Radial Load 16538 lbf
  • Static Radial Load 15638 lbf
  • Lubrication Grease, Oil
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 9000 rpm
  • Weight 0.47 kg
  • Shoulder Dia Of Outer Ring 77.4 mm
  • Raceway Diameter Of Inner Ring 59.5 mm
Single Row Cylindrical Roller Bearings With Inner Ring NU 210 ECPH dimension drawing
Download DWG Download PDF

Features

Performance Features of NU 210 ECPH Bearing

NU 210 ECPH Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 16538 lbf, ensuring reliable performance in demanding conditions.
The PEEK cage keeps the rollers centred, reducing wear and extending service life.
With a maximum speed of 9000 rpm, it balances durability and efficiency.

Application

Industrial Uses of NU 210 ECPH Bearing
NU 210 ECPH Bearing is commonly used in industrial machinery like gearboxes and pumps, where its cylindrical roller design handles combined loads efficiently. The PEEK cage ensures smooth operation even at high speeds, making it suitable for demanding environments.

Where Is NU 210 ECPH Bearing Used?
In automotive applications, NU 210 ECPH Bearing supports components such as transmissions and differentials, thanks to its robust chrome steel construction. Its metric sizing and open design make it easy to integrate into various vehicle models.

Perfect Fit for Automation: NU 210 ECPH Bearing
NU 210 ECPH Bearing works well in robotic arms and automated production lines, where precision and reliability are key. The high-speed capability and temperature resistance ensure consistent performance in continuous operation.

Medical vs Industrial: Where NU 210 ECPH Bearing Excels
NU 210 ECPH Bearing is ideal for medical imaging devices, offering quiet and stable performance. In industrial settings, it excels in heavy machinery due to its high radial load capacity and durability.

Essential Roles of NU 210 ECPH Bearing
NU 210 ECPH Bearing is a reliable choice for fans and blowers, where its grease or oil lubrication options provide flexibility. The wide temperature range makes it adaptable to various operating conditions.
