Single Row Cylindrical Roller Bearings With Inner Ring NU 209 ECPH

Single Row Cylindrical Roller Bearings With Inner Ring NU 209 ECPH

The NU 209 ECPH is a single-row cylindrical roller bearing with a 45mm bore and 85mm outer diameter, crafted from durable chrome steel. It handles combined loads up to 15638 lbf and operates smoothly at speeds up to 10000 RPM.

Its PEEK cage keeps rollers centred for even load distribution, while the open design allows easy lubrication with grease or oil. The bearing performs reliably in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or pumps where radial and axial loads are present.

Weighing 0.44kg, it offers a sturdy yet lightweight solution. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number NU 209 ECPH
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 45 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 85 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 19 mm
  • Width Tolerance -0.12mm to 0
  • Chamfer Dimension r1,2(min.) 1.1 mm
  • Chamfer Dimension r3,4(min.) 1.1 mm
  • Permissible Axial Displacement(max.) 1.2 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • For Load Direction Combined
  • Construction Single Row
  • Inner Ring Type With Inner Ring
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material PEEK cage, roller centred
  • Dynamic Radial Load 15638 lbf
  • Static Radial Load 14400 lbf
  • Lubrication Grease, Oil
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 10000 rpm
  • Weight 0.44 kg
  • Shoulder Dia Of Outer Ring 72.47 mm
  • Raceway Diameter Of Inner Ring 54.5 mm
Single Row Cylindrical Roller Bearings With Inner Ring NU 209 ECPH dimension drawing
Download DWG Download PDF

Features

Why Choose NU 209 ECPH Bearing for Precision Tasks?

NU 209 ECPH Bearing features a chrome steel construction, ensuring durability and resistance to wear.
Its PEEK cage keeps the rollers centred, enhancing stability and reducing friction.
With a dynamic radial load capacity of 15638 lbf, it handles combined loads efficiently.
The bearing operates smoothly at speeds up to 10,000 rpm, making it ideal for high-performance applications.

Application

Key Fields for NU 209 ECPH Bearing
NU 209 ECPH Bearing is commonly used in industrial machinery like pumps and compressors, where its cylindrical roller design handles combined loads efficiently. The PEEK cage ensures smooth operation even at high speeds up to 10000 rpm.

In automotive applications, NU 209 ECPH Bearing fits well in gearboxes and drivetrains, offering reliable performance under heavy radial loads. Its chrome steel construction provides durability in demanding conditions.

For automation systems, NU 209 ECPH Bearing supports robotic arms and conveyor belts, thanks to its precise axial displacement capability. The open seal design allows for easy lubrication maintenance.

NU 209 ECPH Bearing also finds use in wind turbines, where its high dynamic radial load capacity ensures long service life. The metric sizing makes it compatible with various European equipment standards.
