Single Row Cylindrical Roller Bearings With Inner Ring NU 207 ECPH

Single Row Cylindrical Roller Bearings With Inner Ring NU 207 ECPH

The NU 207 ECPH is a single row cylindrical roller bearing with a 35mm bore and 72mm outer diameter, crafted from durable chrome steel. It handles combined loads up to 12600 lbf and spins smoothly at speeds up to 12000 RPM.

Its PEEK cage keeps rollers centred for stable performance, while the open design allows easy lubrication with grease or oil. The bearing operates reliably in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or gearboxes where radial and axial loads are present.

Weighing just 0.3kg, it’s lightweight yet robust for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number NU 207 ECPH
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.12mm to 0
  • Chamfer Dimension r1,2(min.) 1.1 mm
  • Chamfer Dimension r3,4(min.) 0.6 mm
  • Permissible Axial Displacement(max.) 1.3 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • For Load Direction Combined
  • Construction Single Row
  • Inner Ring Type With Inner Ring
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material PEEK cage, roller centred
  • Dynamic Radial Load 12600 lbf
  • Static Radial Load 10800 lbf
  • Lubrication Grease, Oil
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 12000 rpm
  • Weight 0.3 kg
  • Shoulder Dia Of Outer Ring 60.33 mm
  • Raceway Diameter Of Inner Ring 44 mm
Single Row Cylindrical Roller Bearings With Inner Ring NU 207 ECPH dimension drawing
Download DWG Download PDF

Features

Performance Features of NU 207 ECPH Bearing

NU 207 ECPH Bearing is designed with a chrome steel construction, offering high resistance to radial and combined loads.
Its dynamic radial load capacity of 12600 lbf ensures reliable performance in demanding applications.

The PEEK cage keeps the rollers centred, reducing friction and wear for smoother operation.
With a maximum speed of 12,000 rpm, it balances efficiency and durability in various conditions.

NU 207 ECPH Bearing operates effectively in temperatures ranging from -30° to 110°C.
Its open design allows for easy lubrication with grease or oil, extending maintenance intervals.

Application

Industrial Uses of NU 207 ECPH Bearing
NU 207 ECPH Bearing is commonly used in industrial machinery like conveyor systems and gearboxes, where its cylindrical roller design handles combined loads efficiently. The PEEK cage ensures smooth operation even at high speeds up to 12000 rpm.

Where Is NU 207 ECPH Bearing Used?
In automotive applications, NU 207 ECPH Bearing fits well in transmissions and wheel hubs, thanks to its robust chrome steel construction. Its metric sizing makes it a versatile choice for various vehicle models.

Built for Heavy-Duty Use: NU 207 ECPH Bearing
NU 207 ECPH Bearing excels in heavy machinery, such as presses and crushers, where its dynamic radial load capacity of 12600 lbf ensures reliability. The open design allows for easy lubrication and maintenance.

Automotive vs Industrial: Applications of NU 207 ECPH Bearing
NU 207 ECPH Bearing is a go-to for both automotive and industrial settings, balancing high-speed performance with durability. Its temperature range of -30° to 110 °C makes it suitable for diverse operating conditions.

Perfect Fit for Automation: NU 207 ECPH Bearing
NU 207 ECPH Bearing works seamlessly in robotic arms and automated production lines, where precision and speed are key. The roller-centred PEEK cage reduces friction, enhancing longevity.
