Single Row Cylindrical Roller Bearings With Inner Ring NU 207 ECJ

Brand: TFL Bearing Interchangeable: SKF NU 207 ECJ 35 mm × 72 mm × 17 mm Metric Open
Part number: NU 207 ECJ
Single Row Cylindrical Roller Bearings With Inner Ring NU 207 ECJ
In Stock
Price on request
Send your part number and quantity for a quote
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia35 mm
Bore Dia Tolerance-0.012mm to 0
Outer Dia72 mm
Outer Dia Tolerance-0.013mm to 0
Width17 mm
Width Tolerance-0.12mm to 0
Chamfer Dimension r1,2(min.)1.1 mm
Chamfer Dimension r3,4(min.)0.6 mm
Shoulder Dia Of Outer Ring60.33 mm
Raceway Diameter Of Inner Ring44 mm
Performance
Dynamic Radial Load12,600 lbf
Static Radial Load10,800 lbf
Temperature Range-30° to 110 °C
Max Speed12,000 rpm
Characteristics
Permissible Axial Displacement(max.)1.3 mm
System of MeasurementMetric
Roller Bearing TypeCylindrical
For Load DirectionCombined
ConstructionSingle Row
Inner Ring TypeWith Inner Ring
Seal TypeOpen
LubricationGrease, Oil
Weight0.31 kg
Material
Ring MaterialChrome Steel
Roller MaterialChrome Steel
Cage MaterialSteel cage, roller centred
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The NU 207 ECJ is a single row cylindrical roller bearing with a 35mm bore and 72mm outer diameter, crafted from durable chrome steel. It handles combined loads up to 12600 lbf and reaches speeds of 12000 RPM.

Its open design allows for easy lubrication with grease or oil, while the steel cage ensures smooth operation. The bearing performs reliably in temperatures from -30°C to 110°C.

With a compact width of 17mm, it fits well in tight spaces. The chamfered edges (1.1mm and 0.6mm) make installation simpler.

Ideal for industrial machinery or gearboxes where radial and axial loads are present. Compliant with RoHS and REACH standards, it’s a practical choice for replacements, being interchangeable with SKF bearings. Weighing 0.31kg, it’s sturdy yet manageable.

Features

Performance Features of NU 207 ECJ Bearing

NU 207 ECJ Bearing is crafted with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 12,600 lbf, ensuring reliable performance in various applications.

The steel cage keeps the rollers centred, reducing friction and extending service life.
With a maximum speed of 12,000 rpm, it balances durability and efficiency for demanding tasks.

NU 207 ECJ Bearing operates smoothly in temperatures from -30° to 110°C, making it versatile for different environments.
Its open design allows for easy lubrication with grease or oil, reducing maintenance needs.

Application

Industrial Uses of NU 207 ECJ Bearing
NU 207 ECJ Bearing is commonly used in machine tools, where its cylindrical roller design handles high radial loads efficiently. The open seal type allows for easy lubrication, extending its service life in demanding conditions.

In automotive applications, NU 207 ECJ Bearing fits well in gearboxes and wheel hubs, thanks to its combined load capacity. The chrome steel construction ensures durability even under continuous high-speed operation.

For automation systems, NU 207 ECJ Bearing provides reliable performance in robotic arms and conveyor belts. Its steel cage design maintains roller alignment, reducing wear and tear over time.

In industrial fans, NU 207 ECJ Bearing supports smooth rotation with minimal friction. The metric dimensions make it compatible with a wide range of European machinery standards.

NU 207 ECJ Bearing is also found in printing presses, where precision and stability are key. Its temperature range allows it to perform consistently in various operating environments.
