Single Row Cylindrical Roller Bearings With Inner Ring NU 206 ECP

Brand: TFL Bearing Interchangeable: SKF NU 206 ECP 30 mm × 62 mm × 16 mm Metric Open
Part number: NU 206 ECP
Single Row Cylindrical Roller Bearings With Inner Ring NU 206 ECP
In Stock
Price on request
Send your part number and quantity for a quote
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia30 mm
Bore Dia Tolerance-0.01mm to 0
Outer Dia62 mm
Outer Dia Tolerance-0.013mm to 0
Width16 mm
Width Tolerance-0.12mm to 0
Chamfer Dimension r1,2(min.)1 mm
Chamfer Dimension r3,4(min.)0.6 mm
Shoulder Dia Of Outer Ring52.08 mm
Raceway Diameter Of Inner Ring37.5 mm
Performance
Dynamic Radial Load9,900 lbf
Static Radial Load8,212 lbf
Temperature Range-30° to 110 °C
Max Speed14,000 rpm
Characteristics
Permissible Axial Displacement(max.)1.3 mm
System of MeasurementMetric
Roller Bearing TypeCylindrical
For Load DirectionCombined
ConstructionSingle Row
Inner Ring TypeWith Inner Ring
Seal TypeOpen
LubricationGrease, Oil
Weight0.2 kg
Material
Ring MaterialChrome Steel
Roller MaterialChrome Steel
Cage MaterialPA66 cage, roller centred
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The NU 206 ECP is a single row cylindrical roller bearing with a 30mm bore and 62mm outer diameter, crafted from sturdy chrome steel. It handles combined loads up to 9900 lbf and reaches speeds of 14000 RPM.

Its open design allows easy lubrication with grease or oil, while the PA66 cage ensures smooth operation. The bearing performs reliably in temperatures from -30°C to 110°C.

With a compact width of 16mm, it fits well in tight spaces. The chamfered edges (1mm and 0.6mm) make installation simpler.

Ideal for applications like electric motors or gearboxes where radial and axial loads are present. Compliant with RoHS and REACH standards, it’s a practical choice for various industrial uses. Weighing just 0.2kg, it offers durability without adding bulk.

Features

Performance Features of NU 206 ECP Bearing

NU 206 ECP Bearing is crafted with chrome steel rings and rollers, offering robust resistance to combined loads.
Its dynamic radial load capacity reaches 9900 lbf, ensuring dependable performance in various applications.

The PA66 cage keeps the rollers centred, enhancing stability and reducing wear.
With a maximum speed of 14,000 rpm, it delivers both durability and efficiency.

NU 206 ECP Bearing operates smoothly in temperatures from -30° to 110°C.
Its open design allows for easy lubrication with grease or oil, simplifying maintenance.

The precise chamfer dimensions and tolerances ensure easy installation.
This makes NU 206 ECP Bearing a reliable choice for demanding industrial uses.

Application

Industrial Uses of NU 206 ECP Bearing
NU 206 ECP Bearing is commonly used in industrial machinery like pumps and compressors, where its cylindrical roller design handles combined loads efficiently. The open seal type allows for easy lubrication, making it suitable for high-speed operations up to 14000 rpm.

Where Is NU 206 ECP Bearing Used?
You’ll often find NU 206 ECP Bearing in automotive transmissions, where its chrome steel construction ensures durability under heavy radial loads. Its metric sizing makes it a versatile choice for various vehicle models.

Perfect Fit for Automation: NU 206 ECP Bearing
NU 206 ECP Bearing works well in robotic arms and conveyor systems, thanks to its high-speed capability and reliable performance. The PA66 cage material reduces friction, ensuring smooth operation in automated environments.

Medical vs Industrial: Where NU 206 ECP Bearing Excels
In medical devices like centrifuges, NU 206 ECP Bearing provides precise rotation with minimal vibration. For industrial applications, its ability to handle combined loads makes it ideal for machinery requiring both radial and axial support.
