Single Row Cylindrical Roller Bearings With Inner Ring NU 1020 ML

Single Row Cylindrical Roller Bearings With Inner Ring NU 1020 ML

The NU 1020 ML is a single row cylindrical roller bearing with a 100mm bore and 150mm outer diameter, crafted from sturdy chrome steel. It handles combined loads up to 22500 lbf and operates smoothly at speeds up to 8000 RPM.

Its brass cage design ensures durability, while the open seal allows for easy lubrication with grease or oil. The bearing performs reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for industrial machinery or heavy-duty equipment where radial and axial loads are present.

Weighing 1.52kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number NU 1020 ML
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 100 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 150 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 24 mm
  • Width Tolerance -0.20mm to 0
  • Chamfer Dimension r1,2(min.) 1.5 mm
  • Chamfer Dimension r3,4(min.) 1.1 mm
  • Permissible Axial Displacement(max.) 3.5 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • For Load Direction Combined
  • Construction Single Row
  • Inner Ring Type With Inner Ring
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Brass cage, inner or outer ring centred
  • Dynamic Radial Load 22500 lbf
  • Static Radial Load 25650 lbf
  • Lubrication Grease, Oil
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 8000 rpm
  • Weight 1.52 kg
  • Shoulder Dia Of Outer Ring 132.1 mm
  • Raceway Diameter Of Inner Ring 113 mm
Single Row Cylindrical Roller Bearings With Inner Ring NU 1020 ML dimension drawing
Download DWG Download PDF

Features

Performance Features of NU 1020 ML Bearing

NU 1020 ML Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 22,500 lbf, ensuring reliable performance in various applications.

The brass cage design keeps the rollers aligned, reducing wear and extending service life.
With a maximum speed of 8,000 rpm, it balances durability and efficiency.

NU 1020 ML Bearing operates smoothly in temperatures ranging from -30° to 110°C.
Its open design allows for easy lubrication with grease or oil, reducing maintenance needs.

The precise chamfer dimensions of 1.5 mm and 1.1 mm ensure easy installation and alignment.
This bearing is ideal for applications requiring high radial load capacity and long service life.

Application

Essential Roles of NU 1020 ML Bearing
NU 1020 ML Bearing is widely used in industrial machinery, especially in gearboxes and electric motors where combined loads are common. Its brass cage design helps reduce friction, making it suitable for high-speed operations up to 8000 rpm.

What Makes NU 1020 ML Bearing a Preferred Choice?
In automotive applications, NU 1020 ML Bearing handles radial and axial loads in transmissions and wheel hubs. The chrome steel construction ensures durability, even under demanding driving conditions.

Built for Heavy-Duty Use: NU 1020 ML Bearing
This bearing excels in conveyor systems and heavy machinery, thanks to its high dynamic radial load capacity of 22500 lbf. The open seal design allows for easy lubrication, extending its service life.

Medical vs Industrial: Where NU 1020 ML Bearing Excels
While NU 1020 ML Bearing is robust enough for industrial presses, its precision also suits medical imaging devices. The metric dimensions ensure compatibility with a range of equipment across sectors.

Perfect Fit for Automation: NU 1020 ML Bearing
In robotic arms and automated assembly lines, NU 1020 ML Bearing offers reliable performance with minimal maintenance. Its temperature range of -30° to 110°C adapts well to various operating environments.
