Single Row Cylindrical Roller Bearings With Inner Ring NU 1014 ECP

Single Row Cylindrical Roller Bearings With Inner Ring NU 1014 ECP

The NU 1014 ECP is a single row cylindrical roller bearing with a 70mm bore and 110mm outer diameter, crafted from durable chrome steel. It handles combined loads up to 19462 lbf and reaches speeds of 7000 RPM.

Its open design allows for easy lubrication with grease or oil, while the PA66 cage ensures smooth operation. The bearing performs reliably in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for industrial machinery or gearboxes where radial and axial loads are present.

Weighing 0.61kg, it offers a sturdy build for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number NU 1014 ECP
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 70 mm
  • Bore Dia Tolerance -0.15mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 20 mm
  • Width Tolerance -0.15mm to 0
  • Chamfer Dimension r1,2(min.) 1.1 mm
  • Chamfer Dimension r3,4(min.) 1 mm
  • Permissible Axial Displacement(max.) 1.3 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • For Load Direction Combined
  • Construction Single Row
  • Inner Ring Type With Inner Ring
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material PA66 cage, roller centred
  • Dynamic Radial Load 19462 lbf
  • Static Radial Load 20925 lbf
  • Lubrication Grease, Oil
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 7000 rpm
  • Weight 0.61 kg
  • Shoulder Dia Of Outer Ring 97.55 mm
  • Raceway Diameter Of Inner Ring 79.5 mm
Single Row Cylindrical Roller Bearings With Inner Ring NU 1014 ECP dimension drawing
Download DWG Download PDF

Features

Performance Features of NU 1014 ECP Bearing

NU 1014 ECP Bearing is crafted with chrome steel rings and rollers, offering excellent resistance to combined loads.
Its dynamic radial load capacity reaches 19462 lbf, making it suitable for demanding industrial applications.

The PA66 cage keeps the rollers centred, ensuring smooth operation and reduced wear.
With a maximum speed of 7000 rpm, it delivers reliable performance in various conditions.

NU 1014 ECP Bearing operates efficiently in temperatures ranging from -30° to 110°C.
Its open design allows for easy lubrication with grease or oil, enhancing its longevity.

The precise chamfer dimensions of 1.1 mm and 1 mm ensure easy installation and alignment.
This bearing is ideal for applications requiring high radial load capacity and durability.

Application

Industrial Uses of NU 1014 ECP Bearing
NU 1014 ECP Bearing is commonly used in industrial machinery like conveyor systems and gearboxes, where its cylindrical roller design handles combined loads efficiently. The open seal type allows for easy lubrication, making it suitable for high-speed operations up to 7000 rpm.

Where Is NU 1014 ECP Bearing Used?
In automotive applications, NU 1014 ECP Bearing supports components such as transmissions and differentials, thanks to its robust chrome steel construction. The PA66 cage ensures smooth rotation even under heavy radial loads.

Built for Heavy-Duty Use: NU 1014 ECP Bearing
For automation equipment, NU 1014 ECP Bearing provides reliable performance in robotic arms and assembly lines. Its precise tolerances and metric sizing make it a versatile choice for various industrial settings.

Automotive vs Industrial: Applications of NU 1014 ECP Bearing
NU 1014 ECP Bearing excels in both automotive and industrial environments, offering durability in gearboxes and conveyor systems alike. The grease or oil lubrication options adapt to different operational needs.

Essential Roles of NU 1014 ECP Bearing
In medical imaging devices, NU 1014 ECP Bearing ensures smooth and quiet operation, crucial for precision equipment. Its temperature range of -30° to 110°C makes it reliable in diverse conditions.
