Single Row Cylindrical Roller Bearings With Inner Ring NU 1010 ECP

Single Row Cylindrical Roller Bearings With Inner Ring NU 1010 ECP

The NU 1010 ECP is a single row cylindrical roller bearing with a 50mm bore and 80mm outer diameter, crafted from durable chrome steel. It handles combined loads up to 11925 lbf and spins smoothly at speeds up to 10000 RPM.

Its open design allows easy lubrication with grease or oil, while the PA66 cage ensures smooth operation. The bearing performs well in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a reliable choice for replacements. Ideal for applications like electric motors or pumps where radial and axial loads are present.

Weighing just 0.27kg, it’s lightweight yet robust for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number NU 1010 ECP
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 80 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 16 mm
  • Width Tolerance -0.12mm to 0
  • Chamfer Dimension r1,2(min.) 1 mm
  • Chamfer Dimension r3,4(min.) 0.6 mm
  • Permissible Axial Displacement(max.) 1 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • For Load Direction Combined
  • Construction Single Row
  • Inner Ring Type With Inner Ring
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material PA66 cage, roller centred
  • Dynamic Radial Load 11925 lbf
  • Static Radial Load 12600 lbf
  • Lubrication Grease, Oil
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 10000 rpm
  • Weight 0.27 kg
  • Shoulder Dia Of Outer Ring 70.5 mm
  • Raceway Diameter Of Inner Ring 57.5 mm
Single Row Cylindrical Roller Bearings With Inner Ring NU 1010 ECP dimension drawing
Download DWG Download PDF

Features

How Does NU 1010 ECP Bearing Handle Combined Loads?

NU 1010 ECP Bearing is built with chrome steel rings and rollers, offering strong resistance to both radial and axial loads.
Its dynamic radial load capacity reaches 11925 lbf, ensuring reliable performance in demanding conditions.
The PA66 cage keeps the rollers centred, reducing friction and extending service life.
With a maximum speed of 10,000 rpm, it balances durability and efficiency in various applications.

Application

Industrial Uses of NU 1010 ECP Bearing
NU 1010 ECP Bearing is commonly used in industrial machinery like gearboxes and pumps, where its cylindrical roller design handles high radial loads efficiently. The open seal type allows for easy lubrication, making it suitable for demanding environments.

Where Is NU 1010 ECP Bearing Used?
In automotive applications, NU 1010 ECP Bearing supports components such as transmissions and differentials, ensuring smooth performance under combined loads. Its chrome steel construction offers durability and resistance to wear over time.

Perfect Fit for Automation: NU 1010 ECP Bearing
NU 1010 ECP Bearing works well in automated systems like conveyor belts and robotic arms, thanks to its high-speed capability and precise axial displacement. The PA66 cage provides stability and reduces friction during operation.

Medical vs Industrial: Where NU 1010 ECP Bearing Excels
NU 1010 ECP Bearing is ideal for industrial equipment like compressors and electric motors, where reliability is key. Its temperature range and grease lubrication make it adaptable to various operating conditions.
