Single Row Cylindrical Roller Bearings With Inner Ring NJ 322 ECM

Single Row Cylindrical Roller Bearings With Inner Ring NJ 322 ECM

The NJ 322 ECM is a single-row cylindrical roller bearing with a 110mm bore and 240mm outer diameter, built from sturdy chrome steel. It handles combined loads up to 119250 lbf and runs smoothly at speeds up to 3000 RPM.

Its brass cage keeps rollers centred for even load distribution, while the open design allows easy lubrication with grease or oil. The bearing operates well in temperatures from -30°C to 110°C.

With a 50mm width and 3mm chamfers, it fits snugly in tight spaces. The inner ring design ensures stability under heavy radial loads.

Ideal for industrial machinery like gearboxes or pumps where high radial and axial loads are present. Compliant with RoHS and REACH standards, it’s a reliable choice for replacements, interchangeable with SKF bearings. Weighing 11.9kg, it’s robust for demanding applications.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number NJ 322 ECM
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 110 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 240 mm
  • Outer Dia Tolerance -0.03mm to 0
  • Width 50 mm
  • Width Tolerance -0.20mm to 0
  • Shoulder Dia Of Inner Ring 155 mm
  • Chamfer Dimension r1,2(min.) 3 mm
  • Chamfer Dimension r3,4(min.) 3 mm
  • Permissible Axial Displacement(max.) 3 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • For Load Direction Combined
  • Construction Single Row
  • Inner Ring Type With Inner Ring
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Brass cage, roller centred
  • Dynamic Radial Load 119250 lbf
  • Static Radial Load 121500 lbf
  • Lubrication Grease, Oil
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 3000 rpm
  • Weight 11.9 kg
  • Shoulder Dia Of Outer Ring 200.05 mm
  • Raceway Diameter Of Inner Ring 143 mm
Single Row Cylindrical Roller Bearings With Inner Ring NJ 322 ECM dimension drawing
Download DWG Download PDF

Features

Engineered for Precision: NJ 322 ECM Bearing

NJ 322 ECM Bearing features a chrome steel construction, ensuring durability and resistance to heavy loads.
Its dynamic radial load capacity of 119,250 lbf makes it suitable for demanding industrial applications.

The brass cage design keeps the rollers centred, reducing friction and enhancing performance.
With a maximum speed of 3,000 rpm, it balances efficiency and reliability in high-speed operations.

NJ 322 ECM Bearing operates in temperatures from -30° to 110°C, adapting to various working conditions.
Its open design allows for easy lubrication with grease or oil, minimising maintenance requirements.

Application

Industrial Uses of NJ 322 ECM Bearing
NJ 322 ECM Bearing is commonly used in heavy machinery like industrial gearboxes and large conveyor systems, where its cylindrical roller design handles combined loads efficiently. The brass cage ensures smooth operation even at high speeds, making it a reliable choice for demanding environments.

Where Is NJ 322 ECM Bearing Used?
In automotive applications, NJ 322 ECM Bearing supports components such as drivetrains and wheel hubs, thanks to its robust chrome steel construction. Its metric sizing and open design make it easy to integrate into various vehicle models.

Perfect Fit for Automation: NJ 322 ECM Bearing
For automated production lines, NJ 322 ECM Bearing provides precise movement in robotic arms and assembly systems. The high dynamic load capacity ensures long service life, reducing downtime in continuous operations.

Medical vs Industrial: Where NJ 322 ECM Bearing Excels
While NJ 322 ECM Bearing is ideal for industrial equipment like pumps and compressors, its precision also suits medical imaging devices. The temperature range and grease lubrication options make it versatile across different sectors.

Essential Roles of NJ 322 ECM Bearing
In wind turbines, NJ 322 ECM Bearing handles radial and axial loads, ensuring stable performance in harsh weather conditions. The large bore diameter and durable materials make it a key component in renewable energy systems.
