Single Row Cylindrical Roller Bearings With Inner Ring NJ 2212 ECM

Single Row Cylindrical Roller Bearings With Inner Ring NJ 2212 ECM

The NJ 2212 ECM is a single row cylindrical roller bearing with a 60mm bore and 110mm outer diameter, crafted from durable chrome steel. It handles combined loads up to 32850 lbf and operates smoothly at speeds up to 8000 RPM.

Its brass cage keeps rollers centred for even load distribution, while the open design allows easy lubrication with grease or oil. The bearing performs reliably in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for industrial machinery or gearboxes where high radial and axial loads are present.

Weighing 1.26kg, it balances strength and manageability. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number NJ 2212 ECM
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 60 mm
  • Bore Dia Tolerance -0.15mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 28 mm
  • Width Tolerance -0.15mm to 0
  • Shoulder Dia Of Inner Ring 77.5 mm
  • Chamfer Dimension r1,2(min.) 1.5 mm
  • Chamfer Dimension r3,4(min.) 1.5 mm
  • Permissible Axial Displacement(max.) 1.4 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • For Load Direction Combined
  • Construction Single Row
  • Inner Ring Type With Inner Ring
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Brass cage, roller centred
  • Dynamic Radial Load 32850 lbf
  • Static Radial Load 34425 lbf
  • Lubrication Grease, Oil
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 8000 rpm
  • Weight 1.26 kg
  • Shoulder Dia Of Outer Ring 95.1 mm
  • Raceway Diameter Of Inner Ring 72 mm
Single Row Cylindrical Roller Bearings With Inner Ring NJ 2212 ECM dimension drawing
Download DWG Download PDF

Features

Performance Features of NJ 2212 ECM Bearing

NJ 2212 ECM Bearing is built with chrome steel rings and rollers, offering robust resistance to combined loads.
Its dynamic radial load capacity reaches 32850 lbf, ensuring dependable performance in various applications.

The brass cage keeps the rollers centred, reducing friction and enhancing durability.
With a maximum speed of 8000 rpm, it delivers both strength and efficiency.

NJ 2212 ECM Bearing operates smoothly in temperatures ranging from -30° to 110°C.
Its open design allows for easy lubrication with grease or oil, simplifying maintenance.

Application

Industrial Uses of NJ 2212 ECM Bearing
NJ 2212 ECM Bearing is commonly used in heavy machinery like gearboxes and pumps, where its cylindrical roller design handles both radial and axial loads efficiently. The brass cage ensures smooth rotation even at high speeds, making it reliable for continuous operation.

In automotive applications, NJ 2212 ECM Bearing fits well in wheel hubs and transmissions, thanks to its robust chrome steel construction. Its metric sizing makes it a versatile choice for various vehicle models, ensuring compatibility and durability.

For automation systems, NJ 2212 ECM Bearing supports robotic arms and conveyor belts, where precise movement is essential. The open design allows for easy lubrication, extending its lifespan in demanding environments.

In wind turbines, NJ 2212 ECM Bearing’s ability to withstand combined loads makes it ideal for rotor shafts. The temperature range of -30° to 110°C ensures performance in diverse weather conditions.
