Single Row Angular Contact Ball Bearings (General) 7307 BE-2RZP

Single Row Angular Contact Ball Bearings (General) 7307 BE-2RZP

The 7307 BE-2RZP is a single-row angular contact ball bearing with a 35mm bore and 80mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 8775 lbf and operates smoothly at speeds up to 8500 RPM.

Its sealed design keeps lubrication in and contaminants out, while the nylon cage reduces friction for quieter performance. The 40° contact angle makes it ideal for combined radial and axial loads.

This bearing is interchangeable with SKF models, offering a reliable replacement option. Suitable for applications like pumps or electric motors where precision and durability are key.

Weighing 0.45kg, it’s robust yet manageable. Compliant with RoHS and REACH standards, it works in temperatures from -30°C to 110°C.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 7307 BE-2RZP
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • Bearing Type Ball
  • Contact Angle 40°
  • For Load Direction Angular Contact
  • Construction Single Row
  • Seal Type Sealed
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 80 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 21 mm
  • Width Tolerance -0.05mm to 0
  • External Diameter On Inner Ring (Large Side Face) 52.5 mm
  • External Diameter On Inner Ring (Small Side Face) 43.62 mm
  • Chamfer Dimension 1.5 mm
  • Distance Pressure Point (a) 35 mm
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 8775 lbf
  • Static Radial Load 5512 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Tolerance Class P6 (ABEC-3)
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 8500 rpm
  • Weight 0.45 kg
  • Price（$） 15.19
Single Row Angular Contact Ball Bearings (General) 7307 BE-2RZP dimension drawing
Download DWG Download PDF

Features

How Is 7307 BE-2RZP Bearing Engineered for Reliability?

7307 BE-2RZP Bearing features a 40° contact angle, optimising load distribution for angular contact applications.
Its chrome steel rings and balls enhance durability, supporting dynamic radial loads up to 8775 lbf.

The sealed design and nylon cage reduce friction and contamination, ensuring smooth operation.
With a maximum speed of 8,500 rpm, it performs reliably in various industrial settings.

7307 BE-2RZP Bearing operates efficiently within a temperature range of -30° to 110 °C.
Its P6 tolerance class ensures precision and consistency in demanding conditions.

Application

Industrial Uses of 7307 BE-2RZP Bearing
The 7307 BE-2RZP Bearing is commonly used in machine tools, where its 40° contact angle efficiently handles combined radial and axial loads. The sealed design keeps contaminants out, extending service life in dusty workshops.

How Does 7307 BE-2RZP Bearing Improve Performance?
In automotive transmissions, 7307 BE-2RZP Bearing reduces friction, ensuring smoother gear shifts. Its nylon cage dampens vibrations, making it ideal for high-speed applications.

Built for Heavy-Duty Use: 7307 BE-2RZP Bearing
This bearing excels in conveyor systems, where its chrome steel construction withstands constant loads. The P6 tolerance class ensures reliable precision in demanding environments.

Medical vs Industrial: Where 7307 BE-2RZP Bearing Excels
While suitable for industrial pumps, 7307 BE-2RZP Bearing also fits medical centrifuges due to its balanced performance. The lubricated design ensures quiet operation in sensitive settings.

Perfect Fit for Automation: 7307 BE-2RZP Bearing
In robotic arms, 7307 BE-2RZP Bearing offers precise movement control with minimal maintenance. Its metric sizing simplifies integration into European and Asian machinery designs.
