Self Aligning Ball Bearings HIC 2210-2RS

Self Aligning Ball Bearings HIC 2210-2RS

The HIC 2210-2RS is a self-aligning ball bearing with a 50mm bore and 90mm outer diameter, designed for radial loads. Its compact 23mm width makes it suitable for tight spaces, while the double-row construction ensures stability.

Made from chrome steel with a nylon cage, it handles radial loads up to 5152 lbf and operates smoothly at speeds up to 4800 RPM. The sealed design keeps lubrication in and contaminants out, reducing maintenance needs.

This bearing works well in temperatures from -30°C to 110°C, making it versatile for various environments. It’s interchangeable with SKF bearings, offering a reliable replacement option.

Ideal for applications like conveyor systems or agricultural machinery, where misalignment might occur. Weighing 0.57kg, it’s a sturdy yet manageable choice for industrial use. Compliant with RoHS and REACH standards.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number HIC 2210-2RS
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 90 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 23 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 57.7 mm
  • Internal Diameter On Outer Ring 79.4 mm
  • Chamfer Dimension 1.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 5152 lbf
  • Static Radial Load 1834 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 4800 rpm
  • Weight 0.57 kg
Self Aligning Ball Bearings HIC 2210-2RS dimension drawing
Download DWG Download PDF

Features

Why Choose HIC 2210-2RS Bearing for Precision Tasks?

HIC 2210-2RS Bearing features a double-row design with chrome steel rings and balls, ensuring precise radial load handling.

Its dynamic radial load capacity of 5152 lbf makes it suitable for demanding applications.

The sealed construction and nylon cage provide smooth operation and reduce maintenance needs.

With a maximum speed of 4,800 rpm, it balances performance and durability in various conditions.

Application

Common Applications of HIC 2210-2RS Bearing
HIC 2210-2RS Bearing is widely used in industrial machinery, especially in conveyor systems and fans, where its self-aligning feature compensates for minor misalignments. The sealed design keeps contaminants out, ensuring long service life in dusty environments.

What Makes HIC 2210-2RS Bearing a Preferred Choice?
In automotive applications, HIC 2210-2RS Bearing is often found in wheel hubs and transmissions, thanks to its ability to handle radial loads smoothly. The nylon cage reduces friction, making it quieter and more efficient for vehicle use.

Built for Heavy-Duty Use: HIC 2210-2RS Bearing
For automation and robotics, HIC 2210-2RS Bearing provides reliable performance in robotic arms and assembly lines. Its double-row construction offers stability, while the lubricated design ensures consistent operation over time.

Medical vs Industrial: Where HIC 2210-2RS Bearing Excels
In medical devices like MRI machines, HIC 2210-2RS Bearing’s precision and low noise are crucial. Meanwhile, in industrial settings, its durability and ease of maintenance make it a go-to choice for heavy equipment.
