Self Aligning Ball Bearings 2312 KM

Brand: TFL Bearing Interchangeable: SKF 2312 KM 60 mm × 130 mm × 46 mm Metric Open
Part number: 2312 KM
Self Aligning Ball Bearings 2312 KM
In Stock
US$106.81 / piece
Reference price · volume pricing on request
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia60 mm
Bore Dia Tolerance-0.015mm to 0
Outer Dia130 mm
Outer Dia Tolerance-0.018mm to 0
Width46 mm
Width Tolerance-0.15mm to 0
External Diameter On Inner Ring77.1 mm
Internal Diameter On Outer Ring109.2 mm
Chamfer Dimension2.1 mm
Performance
Dynamic Radial Load19,598 lbf
Static Radial Load6,412 lbf
Temperature Range-30° to 110 °C
Max Speed7,000 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
For Load DirectionRadial
ConstructionDouble Row
Seal TypeOpen
LubricationLubricated
Weight2.9 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialNylon
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 2312 KM is a self-aligning ball bearing with a 60mm bore and 130mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 19598 lbf and operates smoothly at speeds up to 7000 RPM.

Its double-row design helps it handle misalignment, while the nylon cage reduces friction for quieter performance. The open seal type allows for easy lubrication and maintenance.

This bearing works well in temperatures from -30°C to 110°C, making it suitable for various environments. It’s interchangeable with SKF bearings, offering a reliable replacement option.

Weighing 2.9kg, it’s robust yet manageable for industrial use. Ideal for applications like conveyor systems or heavy machinery where alignment flexibility is needed. Compliant with RoHS and REACH standards for safety.

Features

Why Choose 2312 KM Bearing for Precision Tasks?

2312 KM Bearing features a double-row design with chrome steel rings and balls, ensuring high radial load capacity.
Its dynamic radial load reaches 19598 lbf, making it suitable for demanding industrial applications.

The nylon cage in 2312 KM Bearing reduces friction and noise, enhancing operational smoothness.
With a maximum speed of 7,000 rpm, it balances performance and durability.

2312 KM Bearing operates efficiently in temperatures ranging from -30° to 110°C.
Its open design allows for easy lubrication, ensuring long service life with minimal maintenance.

Application

Industrial Uses of 2312 KM Bearing
2312 KM Bearing is commonly used in heavy machinery like conveyor systems and industrial fans, where its self-aligning feature compensates for minor misalignments.
The double-row design ensures stable performance under radial loads, making it suitable for long-term use in demanding environments.

Where Is 2312 KM Bearing Used?
In automotive applications, 2312 KM Bearing fits well in gearboxes and wheel hubs, providing smooth rotation even under varying loads.
Its chrome steel construction offers durability, while the nylon cage reduces friction for quieter operation.

Perfect Fit for Automation: 2312 KM Bearing
2312 KM Bearing works efficiently in robotic arms and automated assembly lines, where precision and reliability are key.
The open seal design allows for easy lubrication, extending the bearing’s service life in high-speed operations.

Light-Duty vs Heavy-Duty: Best Uses for 2312 KM Bearing
For light-duty tasks like small electric motors, 2312 KM Bearing delivers consistent performance with minimal maintenance.
In heavy-duty industrial equipment, its robust design handles higher radial loads without compromising efficiency.
