Self Aligning Ball Bearings 2308L1C3

Self Aligning Ball Bearings 2308L1C3

The 2308L1C3 is a self-aligning ball bearing with a 40mm bore and 90mm outer diameter, built from sturdy chrome steel. It manages radial loads up to 7605 lbf and runs smoothly at speeds up to 4800 RPM.

Its double-row design and sealed construction help it handle misalignment while keeping dirt out. The brass cage adds durability, and it comes pre-lubricated for easy use.

This bearing suits applications like conveyor systems or agricultural machinery where alignment might shift. It works in temperatures from -30°C to 110°C.

Weighing 0.96kg, it’s a robust choice for heavy-duty use. Compliant with RoHS and REACH standards, it’s interchangeable with SKF models for straightforward replacements.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2308L1C3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 40 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 90 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 33 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 55.4 mm
  • Internal Diameter On Outer Ring 81.8 mm
  • Chamfer Dimension 1.5 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 7605 lbf
  • Static Radial Load 2520 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance C3
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 4800 rpm
  • Weight 0.96 kg
  • Price（$） 158.75
Self Aligning Ball Bearings 2308L1C3 dimension drawing
Download DWG Download PDF

Features

Why Choose 2308L1C3 Bearing for Precision Tasks?

2308L1C3 Bearing features a double-row design with chrome steel rings and balls, ensuring precise radial load handling.
Its dynamic radial load capacity of 7605 lbf makes it suitable for high-performance applications.

The brass cage maintains ball alignment, reducing friction and enhancing durability.
With a maximum speed of 4,800 rpm, it offers reliable operation in various conditions.

Sealed construction protects against contaminants, extending maintenance intervals.
The C3 radial clearance allows for thermal expansion, ensuring consistent performance.

Application

Industrial Uses of 2308L1C3 Bearing
2308L1C3 Bearing is commonly used in industrial machinery like conveyors and mixers, where its self-aligning feature compensates for minor misalignments. The sealed design helps keep contaminants out, extending the bearing’s lifespan in dusty environments.

In automotive applications, 2308L1C3 Bearing fits well in wheel hubs and transmission systems, offering reliable radial load support. Its brass cage provides smooth operation, even under varying temperatures and loads.

For automation equipment, 2308L1C3 Bearing ensures precise movement in robotic arms and assembly lines. The C3 radial clearance allows for slight thermal expansion, making it suitable for high-speed operations.

Medical devices like diagnostic scanners benefit from 2308L1C3 Bearing’s consistent performance and low maintenance. The chrome steel construction ensures durability in critical healthcare applications.
