Self Aligning Ball Bearings 2222L1KC3

Self Aligning Ball Bearings 2222L1KC3

The 2222L1KC3 is a self-aligning ball bearing with a 110mm tapered bore and 200mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 27900 lbf and operates smoothly at speeds up to 4300 RPM.

Its double-row design and brass cage provide stability and reduce friction, making it suitable for misaligned shafts. The open seal allows for easy lubrication, ensuring long service life.

This bearing works well in temperatures from -30°C to 110°C and is interchangeable with SKF models. Ideal for heavy machinery or industrial equipment where alignment flexibility is needed.

Weighing 7.1kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe and reliable use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2222L1KC3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 110 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 200 mm
  • Outer Dia Tolerance -0.03mm to 0
  • Width 53 mm
  • Width Tolerance -0.2mm to 0
  • External Diameter On Inner Ring 138.5 mm
  • Internal Diameter On Outer Ring 174.3 mm
  • Chamfer Dimension 2.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Taper 1:12
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 27900 lbf
  • Static Radial Load 11700 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance C3
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 4300 rpm
  • Weight 7.1 kg
Self Aligning Ball Bearings 2222L1KC3 dimension drawing
Download DWG Download PDF

Features

Performance Features of 2222L1KC3 Bearing

2222L1KC3 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 27900 lbf, making it suitable for heavy-duty applications.
The brass cage ensures smooth operation by keeping the balls aligned and reducing friction.
With a maximum speed of 4,300 rpm, it delivers reliable performance in various conditions.

How Is 2222L1KC3 Bearing Engineered for Reliability?

2222L1KC3 Bearing features a double-row design, enhancing its load-carrying capacity and stability.
The taper bore design (1:12) allows for secure mounting, reducing the risk of slippage.
Its C3 radial clearance ensures optimal performance under varying thermal conditions.
The bearing operates efficiently within a temperature range of -30° to 110°C.

Designed for Durability: 2222L1KC3 Bearing

2222L1KC3 Bearing’s chrome steel construction provides excellent wear resistance and longevity.
The open seal type allows for easy lubrication, ensuring smooth operation over time.
With a static radial load capacity of 11700 lbf, it handles demanding applications with ease.
Its weight of 7.1 kg reflects its robust build quality.

Ball vs Roller Bearings: Advantages of 2222L1KC3 Bearing

2222L1KC3 Bearing’s self-aligning design compensates for misalignment, reducing stress on the bearing.
The double-row ball arrangement offers higher load capacity compared to single-row designs.
Its brass cage minimizes noise, making it ideal for precision machinery.
The bearing’s lubrication ensures consistent performance and reduces maintenance needs.

Application

Industrial Uses of 2222L1KC3 Bearing
The 2222L1KC3 Bearing is commonly used in heavy machinery like conveyor systems and industrial fans, where its self-aligning feature compensates for shaft misalignment. Its double-row design ensures reliable performance under significant radial loads.

Where Is 2222L1KC3 Bearing Used?
You’ll often find the 2222L1KC3 Bearing in automotive applications such as truck transmissions, where its taper bore provides a secure fit. The brass cage adds durability, making it suitable for high-vibration environments.

Perfect Fit for Automation: 2222L1KC3 Bearing
In robotic arms and automated production lines, the 2222L1KC3 Bearing offers smooth operation thanks to its C3 radial clearance. The chrome steel construction ensures long service life even in continuous use.

Light-Duty vs Heavy-Duty: Best Uses for 2222L1KC3 Bearing
For light-duty applications like small pumps, the 2222L1KC3 Bearing provides sufficient load capacity. In heavy-duty scenarios like mining equipment, its robust design handles extreme conditions with ease.

Medical vs Industrial: Where 2222L1KC3 Bearing Excels
While not typically used in medical devices, the 2222L1KC3 Bearing shines in industrial settings like paper mills. Its lubricated design reduces maintenance needs, ideal for dusty or humid environments.
