Self Aligning Ball Bearings 2218-TVH-C3

Self Aligning Ball Bearings 2218-TVH-C3

The 2218-TVH-C3 is a self-aligning ball bearing with a 90mm bore and 160mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 15795 lbf and operates smoothly at speeds up to 5300 RPM.

Its double-row design and open construction allow for easy lubrication and alignment adjustments, while the nylon cage reduces friction for quieter performance. The bearing works reliably in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like conveyor systems or agricultural machinery where misalignment might occur.

Weighing 3.4kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2218-TVH-C3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 90 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 160 mm
  • Outer Dia Tolerance -0.025mm to 0
  • Width 40 mm
  • Width Tolerance -0.2mm to 0
  • External Diameter On Inner Ring 112.6 mm
  • Internal Diameter On Outer Ring 139.5 mm
  • Chamfer Dimension 2 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 15795 lbf
  • Static Radial Load 6412 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance C3
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 5300 rpm
  • Weight 3.4 kg
  • Price（$） 413.12
Self Aligning Ball Bearings 2218-TVH-C3 dimension drawing
Download DWG Download PDF

Features

How Does 2218-TVH-C3 Bearing Reduce Friction?

2218-TVH-C3 Bearing features a double-row design with chrome steel balls, ensuring smooth radial load distribution.
The nylon cage minimises friction, allowing for quieter operation and reduced energy consumption.

With a dynamic radial load capacity of 15795 lbf, it handles heavy loads efficiently.
Its C3 radial clearance provides optimal performance in various operating conditions.

The bearing operates at speeds up to 5,300 rpm, maintaining reliability.
Its chrome steel construction resists wear, extending service life in demanding applications.

Application

Industrial Uses of 2218-TVH-C3 Bearing
2218-TVH-C3 Bearing is commonly used in heavy machinery, such as conveyor systems and industrial fans, where its double-row design handles misalignment with ease. The open seal type allows for straightforward lubrication, keeping maintenance simple in dusty environments.

In automotive applications, 2218-TVH-C3 Bearing fits well in truck wheel hubs, providing reliable radial load support. Its nylon cage reduces friction, making it a quiet option for long-haul vehicles.

For automation equipment, 2218-TVH-C3 Bearing’s C3 clearance ensures smooth operation in robotic arms and assembly lines. The chrome steel construction offers durability even with frequent direction changes.

Where Is 2218-TVH-C3 Bearing Used?
You’ll often spot 2218-TVH-C3 Bearing in agricultural machinery, like harvesters, where its self-aligning feature compensates for shaft deflections. The metric sizing makes it a versatile pick for European-made equipment.

In construction gear, 2218-TVH-C3 Bearing handles the rough conditions of cement mixers and cranes. Its high dynamic load capacity ensures longevity despite constant heavy use.

Built for Heavy-Duty Use: 2218-TVH-C3 Bearing
2218-TVH-C3 Bearing shines in mining equipment, where its robust design withstands extreme loads and vibrations. The lubricated setup keeps it running smoothly in remote locations.

For paper mills, 2218-TVH-C3 Bearing’s resistance to misalignment prevents downtime in roller systems. The chrome steel balls maintain precision even under continuous operation.
