Self Aligning Ball Bearings 2213 E-2RS1KTN9

Self Aligning Ball Bearings 2213 E-2RS1KTN9

The 2213 E-2RS1KTN9 is a self-aligning ball bearing with a 65mm bore and 120mm outer diameter, built from sturdy chrome steel. It handles radial loads up to 7898 lbf and operates smoothly at speeds up to 3600 RPM.

Its double-row design and sealed construction help it stay aligned and protected from dust, while the nylon cage reduces noise and friction. The bearing comes pre-lubricated for easy installation.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. It works well in temperatures from -30°C to 110°C, suitable for industrial machinery or conveyor systems.

Weighing 1.35kg, it’s a robust option for applications requiring reliable radial load support. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2213 E-2RS1KTN9
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 120 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 31 mm
  • Width Tolerance -0.15mm to 0
  • External Diameter On Inner Ring 79.3 mm
  • Internal Diameter On Outer Ring 105.8 mm
  • Chamfer Dimension 1.5 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 7898 lbf
  • Static Radial Load 3150 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 3600 rpm
  • Weight 1.35 kg
  • Price（$） 133.23
Self Aligning Ball Bearings 2213 E-2RS1KTN9 dimension drawing
Download DWG Download PDF

Features

How Does 2213 E-2RS1KTN9 Bearing Reduce Friction?

2213 E-2RS1KTN9 Bearing features a double-row design with chrome steel rings and balls, ensuring smooth radial load distribution.
The nylon cage helps reduce friction, making it suitable for high-speed applications up to 3,600 rpm.
Its sealed construction keeps lubrication intact, minimising wear and extending service life.
With a dynamic radial load capacity of 7898 lbf, it offers reliable performance in various conditions.

Application

Industrial Uses of 2213 E-2RS1KTN9 Bearing
2213 E-2RS1KTN9 Bearing is commonly used in conveyor systems, where its self-aligning feature compensates for minor misalignments. The sealed design keeps contaminants out, extending service life in dusty environments.

What Makes 2213 E-2RS1KTN9 Bearing a Preferred Choice?
In automotive applications like electric motors, 2213 E-2RS1KTN9 Bearing handles radial loads smoothly while maintaining low friction. The nylon cage reduces noise, making it ideal for quieter vehicle components.

Built for Heavy-Duty Use: 2213 E-2RS1KTN9 Bearing
For industrial fans and blowers, 2213 E-2RS1KTN9 Bearing’s chrome steel construction ensures durability under continuous operation. Its lubricated seals minimise maintenance needs in high-temperature settings.

Automotive vs Industrial: Where 2213 E-2RS1KTN9 Bearing Excels
While 2213 E-2RS1KTN9 Bearing performs well in truck wheel hubs, it’s equally reliable in food processing machinery. The metric sizing allows easy replacement across European equipment standards.

Perfect Fit for Automation: 2213 E-2RS1KTN9 Bearing
In robotic arms, 2213 E-2RS1KTN9 Bearing’s double-row design provides stability during precise movements. The -30° to 110°C range suits various factory conditions without performance loss.
