Self Aligning Ball Bearings 2213 E-2RS1KTN9/C3

Self Aligning Ball Bearings 2213 E-2RS1KTN9/C3

The 2213 E-2RS1KTN9/C3 is a self-aligning ball bearing with a 65mm bore and 120mm outer diameter, designed for radial loads. Its compact 31mm width makes it suitable for tight spaces, while the double-row construction enhances stability.

Made from chrome steel with a nylon cage, it handles dynamic radial loads up to 7898 lbf and spins smoothly at 3600 RPM. The sealed design keeps lubrication in and contaminants out, reducing maintenance needs.

This bearing operates well in temperatures from -30°C to 110°C and features a C3 radial clearance for flexibility. Its tapered bore ensures a secure fit, ideal for applications with slight misalignment.

Interchangeable with SKF bearings, it’s a reliable choice for industrial machinery or conveyors. Weighing 1.35kg, it balances durability with manageable handling. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2213 E-2RS1KTN9/C3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 120 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 31 mm
  • Width Tolerance -0.15mm to 0
  • External Diameter On Inner Ring 79.3 mm
  • Internal Diameter On Outer Ring 105.8 mm
  • Chamfer Dimension 1.5 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Taper 1:12
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 7898 lbf
  • Static Radial Load 3150 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance C3
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 3600 rpm
  • Weight 1.35 kg
  • Price（$） 222.06
Self Aligning Ball Bearings 2213 E-2RS1KTN9/C3 dimension drawing
Download DWG Download PDF

Features

Engineered for Precision: 2213 E-2RS1KTN9/C3 Bearing

2213 E-2RS1KTN9/C3 Bearing features a double-row design with chrome steel rings and balls, ensuring high radial load capacity.
Its dynamic radial load reaches 7898 lbf, making it suitable for demanding applications.

The sealed construction and nylon cage provide smooth operation and reduce maintenance needs.
With a maximum speed of 3,600 rpm, it balances performance and durability.

2213 E-2RS1KTN9/C3 Bearing operates efficiently in temperatures from -30° to 110°C.
Its C3 radial clearance ensures reliable performance under varying conditions.

Application

Industrial Uses of 2213 E-2RS1KTN9/C3 Bearing
2213 E-2RS1KTN9/C3 Bearing is commonly used in conveyor systems, where its self-aligning feature compensates for minor misalignments. The sealed design keeps contaminants out, ensuring long service life in dusty environments.

What Makes 2213 E-2RS1KTN9/C3 Bearing a Preferred Choice?
In automotive applications like electric motors, 2213 E-2RS1KTN9/C3 Bearing handles radial loads efficiently. Its nylon cage reduces friction, making it suitable for high-speed operations.

Perfect Fit for Automation: 2213 E-2RS1KTN9/C3 Bearing
2213 E-2RS1KTN9/C3 Bearing works well in robotic arms, providing smooth movement under varying loads. The C3 radial clearance allows for thermal expansion in continuous operation.

Medical vs Industrial: Where 2213 E-2RS1KTN9/C3 Bearing Excels
In medical devices like centrifuges, 2213 E-2RS1KTN9/C3 Bearing offers reliable performance with minimal maintenance. Its chrome steel construction ensures durability in industrial pumps as well.

Built for Heavy-Duty Use: 2213 E-2RS1KTN9/C3 Bearing
2213 E-2RS1KTN9/C3 Bearing is ideal for fans and blowers, handling radial loads with ease. The lubricated design reduces wear, even in high-temperature environments.
