Self Aligning Ball Bearings 2207-2RS C/3

Self Aligning Ball Bearings 2207-2RS C/3

The 2207-2RS C/3 is a self-aligning ball bearing with a 35mm bore and 72mm outer diameter, designed for radial loads. Its compact size (23mm width) and double-row construction make it sturdy yet space-efficient.

Made from chrome steel with a nylon cage, it handles radial loads up to 4275 lbf and spins smoothly at 6300 RPM. The sealed design keeps lubrication in and contaminants out, reducing maintenance needs.

This bearing can handle slight misalignments, making it ideal for applications like conveyor systems or agricultural machinery. It operates reliably in temperatures from -30°C to 110°C.

Weighing 0.41kg, it’s a robust choice for industrial use. Compliant with RoHS and REACH standards, it’s also interchangeable with SKF bearings for easy replacements.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2207-2RS C/3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 23 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 42.7 mm
  • Internal Diameter On Outer Ring 62.69 mm
  • Chamfer Dimension 1.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 4275 lbf
  • Static Radial Load 1350 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 6300 rpm
  • Weight 0.41 kg
  • Price（$） 54.55
Self Aligning Ball Bearings 2207-2RS C/3 dimension drawing
Download DWG Download PDF

Features

Why Choose 2207-2RS C/3 Bearing for Precision Tasks?

2207-2RS C/3 Bearing features a double-row design with chrome steel rings and balls, ensuring precise radial load handling.
Its dynamic radial load capacity of 4275 lbf makes it suitable for demanding applications.
The sealed construction and nylon cage reduce friction and protect against contaminants.
With a maximum speed of 6,300 rpm, it offers reliable performance in various conditions.

Application

Industrial Uses of 2207-2RS C/3 Bearing
2207-2RS C/3 Bearing is commonly used in conveyor systems, where its self-aligning feature helps handle minor misalignments. The sealed design keeps contaminants out, ensuring longer service life in dusty environments.

Where Is 2207-2RS C/3 Bearing Used?
You’ll often find 2207-2RS C/3 Bearing in agricultural machinery, like harvesters, where it handles radial loads smoothly. Its nylon cage reduces friction, making it efficient for moderate-speed applications.

Built for Heavy-Duty Use: 2207-2RS C/3 Bearing
2207-2RS C/3 Bearing works well in industrial fans, thanks to its double-row construction for added stability. The chrome steel rings provide durability, even in high-temperature settings.

Automotive vs Industrial: Applications of 2207-2RS C/3 Bearing
In automotive applications, 2207-2RS C/3 Bearing supports auxiliary units like water pumps. For industrial use, it’s a reliable choice for pulley systems due to its radial load capacity.

Perfect Fit for Automation: 2207-2RS C/3 Bearing
2207-2RS C/3 Bearing is ideal for robotic arms, where its self-aligning capability compensates for movement variations. The lubricated design ensures smooth operation over long periods.
