Self Aligning Ball Bearings 1317J

Self Aligning Ball Bearings 1317J

The 1317J is a self-aligning ball bearing with an 85mm bore and 180mm outer diameter, crafted from sturdy chrome steel for durability. It handles radial loads up to 21938 lbf and operates smoothly at speeds up to 4800 RPM.

Its double-row design allows for slight misalignment, making it forgiving in less precise setups. The open seal type ensures easy lubrication and maintenance.

This bearing is interchangeable with SKF models, offering a reliable replacement option. Ideal for applications like conveyor systems or agricultural machinery where alignment flexibility is needed.

Weighing 5kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s safe for use in various industrial environments.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 1317J
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 85 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 180 mm
  • Outer Dia Tolerance -0.025mm to 0
  • Width 41 mm
  • Width Tolerance -0.2mm to 0
  • External Diameter On Inner Ring 117.6 mm
  • Internal Diameter On Outer Ring 152.8 mm
  • Chamfer Dimension 3 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 21938 lbf
  • Static Radial Load 8550 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 4800 rpm
  • Weight 5 kg
  • Price（$） 292.55
Self Aligning Ball Bearings 1317J dimension drawing
Download DWG Download PDF

Features

Why Choose 1317J Bearing for Precision Tasks?

1317J Bearing features a double-row design, enhancing its radial load capacity to 21938 lbf for stable performance.
Its chrome steel rings and balls ensure durability, while the steel cage maintains precise ball alignment.
The bearing operates smoothly at speeds up to 4,800 rpm, suitable for various industrial applications.
With a temperature range of -30° to 110°C, it adapts well to different working environments.

Application

Industrial Uses of 1317J Bearing
1317J Bearing is commonly used in heavy machinery, such as conveyor systems and industrial fans, where its double-row design helps manage radial loads efficiently. The open seal type allows for easy lubrication, extending its service life in demanding environments.

What Makes 1317J Bearing a Preferred Choice?
In automotive applications, 1317J Bearing fits well in gearboxes and drivetrains, thanks to its cylindrical bore and chrome steel construction. Its ability to handle high dynamic loads makes it reliable for long-term use.

Perfect Fit for Automation: 1317J Bearing
For robotics and automated systems, 1317J Bearing offers smooth operation in mechanical arms and assembly lines. The steel cage ensures durability, even in high-speed scenarios.

Medical vs Industrial: Where 1317J Bearing Excels
While 1317J Bearing is robust enough for industrial equipment, its precision also suits medical devices like diagnostic machines. The consistent performance under radial loads makes it versatile across sectors.
