Self Aligning Ball Bearings 1316C3

Self Aligning Ball Bearings 1316C3

The 1316C3 is a self-aligning ball bearing with an 80mm bore and 170mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 19890 lbf and operates smoothly at speeds up to 5300 RPM.

Its double-row design allows for slight misalignment, while the open seal type ensures easy lubrication. The stainless steel cage adds durability, making it suitable for heavy-duty use.

This bearing works well in temperatures ranging from -30°C to 110°C. It’s interchangeable with SKF models, offering a reliable replacement option.

Weighing 4.2kg, it’s robust yet manageable for industrial applications like conveyor systems or electric motors. Compliant with RoHS and REACH standards for safe usage.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 1316C3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 80 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 170 mm
  • Outer Dia Tolerance -0.025mm to 0
  • Width 39 mm
  • Width Tolerance -0.15mm to 0
  • External Diameter On Inner Ring 110 mm
  • Internal Diameter On Outer Ring 144.4 mm
  • Chamfer Dimension 2.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 19890 lbf
  • Static Radial Load 7538 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance C3
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 5300 rpm
  • Weight 4.2 kg
  • Price（$） 226.82
Self Aligning Ball Bearings 1316C3 dimension drawing
Download DWG Download PDF

Features

Performance Features of 1316C3 Bearing

1316C3 Bearing is crafted with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 19890 lbf, ensuring reliable performance in demanding applications.

The double-row design of 1316C3 Bearing enhances load distribution, reducing stress on individual components.
With a maximum speed of 5,300 rpm, it balances durability and efficiency for various industrial uses.

1316C3 Bearing operates smoothly within a temperature range of -30° to 110°C, adapting to diverse environments.
Its stainless steel cage maintains ball alignment, minimising wear and extending service life.

Application

Common Applications of 1316C3 Bearing
In industrial settings, 1316C3 Bearing is widely used in conveyor systems and heavy machinery, thanks to its self-aligning feature that compensates for minor misalignments. The double-row design ensures stable performance under radial loads, making it a reliable choice for continuous operation.

Where Is 1316C3 Bearing Used?
You’ll often find 1316C3 Bearing in automotive applications like gearboxes and wheel hubs, where its high dynamic radial load capacity handles demanding conditions. The C3 clearance also allows for thermal expansion, ensuring consistent performance in varying temperatures.

Built for Heavy-Duty Use: 1316C3 Bearing
1316C3 Bearing excels in agricultural equipment, such as tractors and harvesters, where dirt and debris are common. Its open design and stainless steel cage make it easier to clean and maintain, even in harsh environments.

Automotive vs Industrial: Applications of 1316C3 Bearing
In automotive systems, 1316C3 Bearing supports smooth rotation in drivetrains, while in industrial fans, it handles high-speed radial loads with ease. The chrome steel construction ensures longevity in both scenarios.

Perfect Fit for Automation: 1316C3 Bearing
1316C3 Bearing is a go-to for robotic arms and automated assembly lines, where precision and durability are key. Its self-aligning capability reduces wear, even if components aren’t perfectly aligned during installation.
