Self Aligning Ball Bearings 1316/C3

The 1316/C3 is a self-aligning ball bearing with an 80mm bore and 170mm outer diameter, built to handle radial loads up to 19890 lbf. Its double-row design and chrome steel construction ensure durability and smooth operation at speeds up to 5300 RPM.

The open seal type allows for easy lubrication, while the stainless steel cage enhances longevity. With a C3 radial clearance, it accommodates slight misalignments, making it versatile for various setups.

This bearing works well in temperatures from -30°C to 110°C and is interchangeable with SKF models, ideal for industrial machinery or heavy-duty equipment. Weighing 4.2kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number 1316/C3
Brand TFL & OEM
Interchangeable SKF
Bore Dia 80 mm
Bore Dia Tolerance -0.015mm to 0
Outer Dia 170 mm
Outer Dia Tolerance -0.025mm to 0
Width 39 mm
Width Tolerance -0.15mm to 0
External Diameter On Inner Ring 110 mm
Internal Diameter On Outer Ring 144.4 mm
Chamfer Dimension 2.1 mm
System of Measurement Metric
Bearing Type Ball
Bore Type Cylindrical
For Load Direction Radial
Construction Double Row
Seal Type Open
Ring Material Chrome Steel
Ball Material Chrome Steel
Cage Material Stainless Steel
Dynamic Radial Load 19890 lbf
Static Radial Load 7538 lbf
Lubrication Lubricated
Temperature Range -30° to 110 °C
Radial Clearance C3
RoHS Compliant
REACH Compliant
Max Speed 5300 rpm
Weight 4.2 kg
Price（$） 229.06

Self Aligning Ball Bearings 1316/C3 dimension drawing

Download DWG Download PDF

Features

Why Choose 1316/C3 Bearing for Precision Tasks?

1316/C3 Bearing features a double-row design with chrome steel rings and balls, ensuring high radial load capacity.
Its dynamic radial load reaches 19890 lbf, making it suitable for demanding applications.

The stainless steel cage maintains ball alignment, reducing friction and wear.
With a maximum speed of 5,300 rpm, it offers reliable performance in various conditions.

1316/C3 Bearing operates efficiently within a temperature range of -30° to 110°C.
Its C3 radial clearance allows for thermal expansion, ensuring consistent operation.

The open seal design simplifies maintenance while the cylindrical bore ensures easy installation.
This bearing is ideal for applications requiring precision and durability.

Application

Industrial Uses of 1316/C3 Bearing
1316/C3 Bearing is commonly used in heavy machinery like conveyors and mixers, where its double-row design helps manage misalignment and radial loads. The open seal type makes it easy to relubricate, extending its service life in demanding conditions.

Where Is 1316/C3 Bearing Used?
You’ll often find 1316/C3 Bearing in automotive applications such as wheel hubs, where its high dynamic radial load capacity ensures smooth performance. Its metric sizing also makes it a versatile fit for various European and Asian vehicle designs.

Perfect Fit for Automation: 1316/C3 Bearing
In robotic arms and automated production lines, 1316/C3 Bearing’s self-aligning feature compensates for shaft misalignment, reducing wear. The chrome steel construction adds durability, making it reliable for continuous operation.

Medical vs Industrial: Where 1316/C3 Bearing Excels
While 1316/C3 Bearing handles industrial loads well, its precision also suits medical devices like MRI machines, where consistent rotation is key. The stainless steel cage ensures minimal friction, even in high-use scenarios.

Light-Duty vs Heavy-Duty: Best Uses for 1316/C3 Bearing
For lighter tasks like electric motors, 1316/C3 Bearing offers quiet operation, while its robust build shines in heavy-duty pumps. The C3 clearance provides flexibility across temperature changes.
