Self Aligning Ball Bearings 1315KJ

Self Aligning Ball Bearings 1315KJ

The 1315KJ is a self-aligning ball bearing with a 75mm tapered bore and 160mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 17842 lbf and operates smoothly at speeds up to 5600 RPM.

Its double-row design and open seal ensure reliable performance, while the steel cage adds durability. The bearing works efficiently in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like conveyor systems or agricultural machinery where misalignment might occur.

Weighing 3.55kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 1315KJ
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 75 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 160 mm
  • Outer Dia Tolerance -0.025mm to 0
  • Width 37 mm
  • Width Tolerance -0.15mm to 0
  • External Diameter On Inner Ring 104.8 mm
  • Internal Diameter On Outer Ring 135.2 mm
  • Chamfer Dimension 2.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Taper 1:12
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 17842 lbf
  • Static Radial Load 6750 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 5600 rpm
  • Weight 3.55 kg
  • Price（$） 203.97
Self Aligning Ball Bearings 1315KJ dimension drawing
Download DWG Download PDF

Features

Why Choose 1315KJ Bearing for Precision Tasks?

1315KJ Bearing features a double-row design with chrome steel rings and balls, ensuring high radial load capacity.
Its dynamic radial load reaches 17842 lbf, making it suitable for demanding applications.

The tapered bore design of 1315KJ Bearing allows for precise alignment, reducing wear and improving performance.
With a maximum speed of 5,600 rpm, it balances efficiency and durability.

1315KJ Bearing operates smoothly in temperatures ranging from -30° to 110°C, adapting to various conditions.
Its steel cage maintains ball alignment, extending the bearing’s service life.

The open seal type of 1315KJ Bearing simplifies maintenance while ensuring reliable operation.
Its radial clearance classification (CN) provides consistent performance under different loads.

Application

Industrial Uses of 1315KJ Bearing
1315KJ Bearing is commonly used in heavy machinery like conveyor systems, where its self-aligning feature compensates for minor misalignments. The double-row design ensures reliable performance under substantial radial loads.

Where Is 1315KJ Bearing Used?
In automotive applications, 1315KJ Bearing fits well in gearboxes and drivetrains, handling high radial forces with ease. Its taper bore design allows for secure mounting on shafts, reducing slippage risks.

Built for Heavy-Duty Use: 1315KJ Bearing
For industrial fans and blowers, 1315KJ Bearing’s chrome steel construction offers durability in high-speed operations. The open seal type simplifies lubrication, extending service life in dusty environments.

Automotive vs Aerospace: Applications of 1315KJ Bearing
While 1315KJ Bearing excels in automotive drivetrains, it’s also suitable for aerospace auxiliary systems where radial load capacity matters. The metric sizing ensures compatibility with diverse equipment standards.

Perfect Fit for Automation: 1315KJ Bearing
In robotic arms, 1315KJ Bearing’s self-aligning capability ensures smooth movement despite operational vibrations. The steel cage provides stability, making it a dependable choice for precision tasks.
