Self Aligning Ball Bearings 1313

Self Aligning Ball Bearings 1313

The 1313 is a self-aligning ball bearing with a 65mm bore and 100mm outer diameter, crafted from sturdy 52100 chrome steel. It manages radial loads up to 3985 lbf and operates smoothly at speeds up to 3280 RPM.

Its open design simplifies lubrication, while the chrome steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. Suitable for machinery where slight misalignments may occur, such as conveyor systems or agricultural equipment.

Weighing 0.82kg, it balances strength with manageable size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 1313
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 100 mm
  • Outer Dia Tolerance -0.02mm to 0
  • Width 32 mm
  • Width Tolerance +0.02mm to -0.3mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Seal Type Open
  • Ring Material 52100 Chrome Steel
  • Ball Material 52100 Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 3985 lbf
  • Static Radial Load 28400 lbf
  • Lubrication Required
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 3280 rpm
  • Weight 0.82 kg
Self Aligning Ball Bearings 1313 dimension drawing
Download DWG Download PDF

Features

How Does 1313 Bearing Reduce Friction?

1313 Bearing is crafted from 52100 chrome steel, known for its smooth surface and low friction properties.
The open seal design allows for easy lubrication, further reducing friction during operation.
Its dynamic radial load capacity of 3985 lbf ensures reliable performance under pressure.
With a maximum speed of 3,280 rpm, it offers a balance of efficiency and durability.

Application

Industrial Uses of 1313 Bearing
1313 Bearing is commonly used in heavy machinery like conveyor systems and industrial fans, where its self-aligning feature helps compensate for misalignment. The chrome steel construction ensures durability in demanding environments.

What Makes 1313 Bearing a Preferred Choice?
In automotive applications, 1313 Bearing fits well in suspension systems and gearboxes, providing reliable performance under radial loads. Its metric sizing makes it easy to integrate into various vehicle designs.

Built for Heavy-Duty Use: 1313 Bearing
For automation equipment, 1313 Bearing supports smooth operation in robotic arms and assembly lines. The open design allows for easy lubrication, extending its service life.

Medical vs Industrial: Where 1313 Bearing Excels
In medical devices like imaging equipment, 1313 Bearing offers precision and reliability. Its chrome steel balls and cage ensure minimal wear during continuous use.

Practical Applications of 1313 Bearing
1313 Bearing is also found in household appliances like washing machines, where its self-aligning capability reduces noise and vibration. The wide temperature range makes it suitable for various climates.
