Self Aligning Ball Bearings 1307G15C3

Brand: TFL Bearing Interchangeable: SKF 1307G15C3 35 mm × 80 mm × 21 mm Metric Open
Part number: 1307G15C3
Self Aligning Ball Bearings 1307G15C3
In Stock
Price on request
Send your part number and quantity for a quote
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia35 mm
Bore Dia Tolerance-0.012mm to 0
Outer Dia80 mm
Outer Dia Tolerance-0.013mm to 0
Width21 mm
Width Tolerance-0.12mm to 0
External Diameter On Inner Ring51.55 mm
Internal Diameter On Outer Ring67.5 mm
Chamfer Dimension1.5 mm
Performance
Dynamic Radial Load5,962 lbf
Static Radial Load1,912 lbf
Temperature Range-30° to 110 °C
Max Speed11,000 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Bore TypeCylindrical
For Load DirectionRadial
ConstructionDouble Row
Seal TypeOpen
LubricationLubricated
Radial ClearanceC3
Weight0.51 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialNylon
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 1307G15C3 is a self-aligning ball bearing with a 35mm bore and 80mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 5962 lbf and operates smoothly at speeds up to 11000 RPM.

Its double-row design and open seal allow for easy alignment and maintenance, while the nylon cage reduces friction. The bearing works reliably in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like conveyor systems or agricultural machinery where misalignment might occur.

Weighing 0.51kg, it’s a robust yet manageable size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Features

Performance Features of 1307G15C3 Bearing

1307G15C3 Bearing features a double-row ball design, providing excellent radial load capacity up to 5962 lbf.
Its chrome steel rings and balls ensure durability, while the nylon cage reduces friction for smoother operation.

The C3 radial clearance allows for thermal expansion, making it suitable for varying operating conditions.
With a maximum speed of 11,000 rpm, it delivers reliable performance in high-speed applications.

1307G15C3 Bearing operates efficiently within a temperature range of -30° to 110°C.
Its open seal design simplifies maintenance, ensuring long service life with minimal upkeep.

Application

Industrial Uses of 1307G15C3 Bearing
1307G15C3 Bearing is commonly used in industrial machinery like pumps and compressors, where its double-row design helps handle misalignment and radial loads. The open seal type allows for easy lubrication, extending its service life in demanding conditions.

What Makes 1307G15C3 Bearing a Preferred Choice?
In automotive applications, 1307G15C3 Bearing works well in wheel hubs and transmissions, thanks to its durable chrome steel construction. The C3 radial clearance ensures smooth performance even under varying temperatures and loads.

Perfect Fit for Automation: 1307G15C3 Bearing
For robotics and automated systems, 1307G15C3 Bearing offers reliable performance in joints and pivots. Its nylon cage reduces friction, making it suitable for high-speed operations.

Medical vs Industrial: Where 1307G15C3 Bearing Excels
While 1307G15C3 Bearing is robust enough for heavy machinery, it also meets the precision needs of medical devices like lab equipment. The metric sizing ensures compatibility with a wide range of European and Asian standards.

Where Is 1307G15C3 Bearing Used?
You’ll often find 1307G15C3 Bearing in household appliances like washing machines, where its self-aligning feature compensates for minor misalignments. The lubricated design keeps it running quietly and efficiently.
