Self Aligning Ball Bearings 1226 M

Self Aligning Ball Bearings 1226 M

The 1226 M is a self-aligning ball bearing with a 130mm bore and 230mm outer diameter, built from sturdy chrome steel. It handles radial loads up to 28575 lbf and operates smoothly at speeds up to 3600 RPM.

Its double-row design and nylon cage help it adjust to misalignment while reducing friction. The open seal type allows for easy lubrication and maintenance.

This bearing works well in temperatures from -30°C to 110°C and is interchangeable with SKF models. Ideal for heavy machinery or conveyor systems where alignment flexibility is needed.

Weighing 8.3kg, it’s a robust choice for industrial applications. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 1226 M
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 130 mm
  • Bore Dia Tolerance -0.025mm to 0
  • Outer Dia 230 mm
  • Outer Dia Tolerance -0.03mm to 0
  • Width 46 mm
  • Width Tolerance -0.25mm to 0
  • External Diameter On Inner Ring 163 mm
  • Internal Diameter On Outer Ring 201.4 mm
  • Chamfer Dimension 3 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 28575 lbf
  • Static Radial Load 13162 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 3600 rpm
  • Weight 8.3 kg
  • Price（$） 706.06
Self Aligning Ball Bearings 1226 M dimension drawing
Download DWG Download PDF

Features

Performance Features of 1226 M Bearing

1226 M Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 28,575 lbf, ensuring reliable performance in heavy-duty applications.
The nylon cage keeps the balls aligned, reducing friction and extending service life.
With a maximum speed of 3,600 rpm, it balances durability and efficiency.

Application

Common Applications of 1226 M Bearing
In industrial settings, 1226 M Bearing is commonly used in heavy machinery like conveyors and mixers, where its double-row design handles misalignment with ease. The chrome steel construction ensures durability in demanding environments.

Where Is 1226 M Bearing Used?
You’ll often find 1226 M Bearing in automotive applications, particularly in wheel hubs and transmissions, where its radial load capacity is essential. The nylon cage reduces friction, making it a reliable choice for long-term use.

Built for Heavy-Duty Use: 1226 M Bearing
For automation systems, 1226 M Bearing supports robotic arms and assembly lines, thanks to its ability to manage radial loads smoothly. Its open seal design allows for easy lubrication, extending service life.

Industrial vs Automotive: Applications of 1226 M Bearing
In industrial fans, 1226 M Bearing’s self-aligning feature compensates for shaft misalignment, reducing wear. Meanwhile, in automotive systems, it ensures smooth rotation in drivetrain components. The metric sizing makes it versatile for various applications.
