Self Aligning Ball Bearings 1224 M C/3

Self Aligning Ball Bearings 1224 M C/3

The 1224 M C/3 is a self-aligning ball bearing with a 120mm bore and 215mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 26775 lbf and operates smoothly at speeds up to 4000 RPM.

Its double-row design and brass cage provide durability and reduce friction, while the open seal allows for easy lubrication. The bearing performs reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like conveyor systems or agricultural machinery where misalignment might occur.

Weighing 6.75kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 1224 M C/3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 120 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 215 mm
  • Outer Dia Tolerance -0.03mm to 0
  • Width 42 mm
  • Width Tolerance -0.2mm to 0
  • External Diameter On Inner Ring 149 mm
  • Internal Diameter On Outer Ring 187.2 mm
  • Chamfer Dimension 2.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 26775 lbf
  • Static Radial Load 11925 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 4000 rpm
  • Weight 6.75 kg
  • Price（$） 881.21
Self Aligning Ball Bearings 1224 M C/3 dimension drawing
Download DWG Download PDF

Features

How Does 1224 M C/3 Bearing Reduce Friction?

1224 M C/3 Bearing features a double-row design with chrome steel balls, ensuring smooth radial load distribution.
Its brass cage helps maintain ball alignment, reducing friction and wear during operation.

The bearing’s dynamic radial load capacity of 26775 lbf makes it suitable for heavy-duty applications.
With a maximum speed of 4,000 rpm, it balances performance and durability.

1224 M C/3 Bearing operates efficiently in temperatures ranging from -30° to 110°C.
Its open design allows for easy lubrication, ensuring long service life with minimal maintenance.

Application

Industrial Uses of 1224 M C/3 Bearing
1224 M C/3 Bearing is commonly used in heavy machinery, such as conveyor systems and industrial fans, where its self-aligning feature compensates for minor misalignments. The double-row design ensures reliable radial load handling, making it suitable for demanding environments.

Where Is 1224 M C/3 Bearing Used?
In automotive applications, 1224 M C/3 Bearing can be found in gearboxes and drivetrains, where its brass cage reduces friction and wear. The metric dimensions make it a versatile choice for various vehicle models.

Built for Heavy-Duty Use: 1224 M C/3 Bearing
For construction equipment, 1224 M C/3 Bearing provides durability in cranes and excavators, handling high radial loads with ease. The chrome steel construction ensures long service life even under tough conditions.

Automotive vs Aerospace: Applications of 1224 M C/3 Bearing
While 1224 M C/3 Bearing is popular in automotive gearboxes, it also finds use in aerospace landing gear systems. Its self-aligning capability is particularly useful in applications where precision alignment is challenging.

Essential Roles of 1224 M C/3 Bearing
In agricultural machinery, 1224 M C/3 Bearing supports equipment like harvesters and tractors, where its robust design withstands dust and debris. The lubricated construction helps maintain smooth operation in harsh outdoor conditions.
