Self Aligning Ball Bearings 1217-K-TVH-C3

Self Aligning Ball Bearings 1217-K-TVH-C3

The 1217-K-TVH-C3 is a self-aligning ball bearing with an 85mm tapered bore and 150mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 10980 lbf and runs smoothly at speeds reaching 5600 RPM.

Its double-row design and open seal allow for easy lubrication, while the nylon cage reduces friction for quieter operation. The bearing operates reliably in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. Suitable for machinery with misalignment issues, such as conveyor systems or agricultural equipment.

Weighing 2.05kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 1217-K-TVH-C3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 85 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 150 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 28 mm
  • Width Tolerance -0.2mm to 0
  • External Diameter On Inner Ring 107 mm
  • Internal Diameter On Outer Ring 131 mm
  • Chamfer Dimension 2 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Taper 1:12
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 10980 lbf
  • Static Radial Load 4680 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance C3
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 5600 rpm
  • Weight 2.05 kg
  • Price（$） 129.82
Self Aligning Ball Bearings 1217-K-TVH-C3 dimension drawing
Download DWG Download PDF

Features

Performance Features of 1217-K-TVH-C3 Bearing

1217-K-TVH-C3 Bearing is designed with a double-row ball construction, offering excellent radial load capacity.
Its dynamic radial load reaches 10,980 lbf, making it suitable for heavy-duty applications.

The chrome steel rings and balls provide durability, while the nylon cage reduces friction and noise.
This combination ensures smooth operation even at high speeds up to 5,600 rpm.

With a C3 radial clearance, 1217-K-TVH-C3 Bearing accommodates thermal expansion in various operating conditions.
Its tapered bore design simplifies installation and enhances alignment accuracy.

The bearing operates efficiently in temperatures ranging from -30° to 110°C.
Its open seal type allows for easy relubrication, extending service life.

Application

Industrial Uses of 1217-K-TVH-C3 Bearing
1217-K-TVH-C3 Bearing is commonly used in industrial settings, especially in conveyor systems and heavy machinery where radial load support is needed. Its double-row design helps accommodate slight misalignments, making it reliable for continuous operation.

Where Is 1217-K-TVH-C3 Bearing Used?
You’ll often find 1217-K-TVH-C3 Bearing in automotive applications like gearboxes and drivetrains, where its tapered bore ensures a secure fit. The chrome steel construction also provides durability under high-stress conditions.

Built for Heavy-Duty Use: 1217-K-TVH-C3 Bearing
In automation and robotics, 1217-K-TVH-C3 Bearing works well in robotic arms and assembly lines due to its self-aligning feature. The nylon cage reduces friction, contributing to smoother movement over time.

Medical vs Industrial: Where 1217-K-TVH-C3 Bearing Excels
While 1217-K-TVH-C3 Bearing is robust enough for industrial machinery, its precision also suits medical imaging devices. The C3 radial clearance ensures consistent performance in varying temperature conditions.

Practical Applications of 1217-K-TVH-C3 Bearing
For household appliances like washing machines, 1217-K-TVH-C3 Bearing offers quiet and efficient operation. Its lubricated design minimises maintenance, making it a hassle-free choice for everyday use.
