Self Aligning Ball Bearings 1207-TVH

Self Aligning Ball Bearings 1207-TVH

The 1207-TVH is a self-aligning ball bearing with a 35mm bore and 72mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 4275 lbf and operates smoothly at speeds reaching 13,000 RPM.

Its double-row design and open seal allow for slight misalignments, while the nylon cage reduces friction and noise. The bearing is pre-lubricated for easy use and works in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a reliable alternative for replacements. Perfect for applications like conveyor systems or agricultural machinery where alignment flexibility is needed.

Weighing 0.32kg, it’s a durable yet lightweight option. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 1207-TVH
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 47 mm
  • Internal Diameter On Outer Ring 60.9 mm
  • Chamfer Dimension 1.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 4275 lbf
  • Static Radial Load 1350 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 13000 rpm
  • Weight 0.32 kg
  • Price（$） 25.32
Self Aligning Ball Bearings 1207-TVH dimension drawing
Download DWG Download PDF

Features

How Does 1207-TVH Bearing Reduce Friction?

1207-TVH Bearing features a double-row design with chrome steel rings and balls, ensuring smooth radial load distribution.
Its nylon cage minimises friction, allowing for quieter operation and extended service life.

The bearing’s lubrication reduces wear, maintaining performance even at high speeds up to 13,000 rpm.
With a dynamic radial load capacity of 4275 lbf, it handles demanding applications with ease.

1207-TVH Bearing operates efficiently in temperatures ranging from -30° to 110°C, making it versatile for various conditions.
Its open seal design simplifies maintenance while keeping contaminants at bay.

Application

Industrial Uses of 1207-TVH Bearing
1207-TVH Bearing is commonly used in industrial fans and blowers, where its self-aligning feature compensates for minor misalignments. The double-row design provides stable radial load support, ensuring smooth operation in demanding environments.

What Makes 1207-TVH Bearing a Preferred Choice?
In conveyor systems, 1207-TVH Bearing’s nylon cage reduces friction and noise, making it ideal for continuous operation. Its metric sizing ensures compatibility with a variety of European machinery standards.

Perfect Fit for Automation: 1207-TVH Bearing
For robotic arms, 1207-TVH Bearing offers reliable performance with its chrome steel construction and lubricated design. The wide temperature range allows it to function efficiently in both hot and cold conditions.

Automotive vs Industrial: Applications of 1207-TVH Bearing
In automotive applications like pumps, 1207-TVH Bearing handles radial loads effectively, while its industrial use in gearboxes showcases its versatility. The open seal type simplifies maintenance in both settings.
