Self Aligning Ball Bearings 1207-K-TVH-C3

Self Aligning Ball Bearings 1207-K-TVH-C3

The 1207-K-TVH-C3 is a self-aligning ball bearing with a 35mm bore and 72mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 4275 lbf and operates smoothly at speeds up to 13000 RPM.

Its double-row design and open seal allow for easy lubrication, while the nylon cage reduces friction for quieter performance. The bearing works well in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like conveyor systems or agricultural machinery where misalignment might occur.

Weighing just 0.32kg, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe and reliable use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 1207-K-TVH-C3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 47 mm
  • Internal Diameter On Outer Ring 60.9 mm
  • Chamfer Dimension 1.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Taper 1:12
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 4275 lbf
  • Static Radial Load 1350 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance C3
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 13000 rpm
  • Weight 0.32 kg
  • Price（$） 25.32
Self Aligning Ball Bearings 1207-K-TVH-C3 dimension drawing
Download DWG Download PDF

Features

Why Choose 1207-K-TVH-C3 Bearing for Precision Tasks?

1207-K-TVH-C3 Bearing features a double-row design with chrome steel rings and balls, ensuring precise radial load handling.
Its dynamic radial load capacity of 4275 lbf makes it suitable for high-performance applications.

The nylon cage maintains ball alignment, reducing friction and noise during operation.
With a maximum speed of 13,000 rpm, it delivers both speed and reliability.

1207-K-TVH-C3 Bearing operates efficiently in temperatures from -30° to 110°C, adapting to various environments.
Its C3 radial clearance provides optimal performance under varying load conditions.

The tapered bore design simplifies installation, saving time and effort.
Lubricated for smooth operation, it requires minimal maintenance over its long service life.

Application

Industrial Uses of 1207-K-TVH-C3 Bearing
The 1207-K-TVH-C3 Bearing is commonly used in industrial fans and blowers, where its self-aligning feature compensates for minor misalignments. Its double-row design provides reliable radial load support, ensuring smooth operation in demanding environments.

Where Is 1207-K-TVH-C3 Bearing Used?
In conveyor systems, the 1207-K-TVH-C3 Bearing handles radial loads efficiently, thanks to its chrome steel construction. The nylon cage reduces friction, making it suitable for continuous operation in material handling equipment.

Built for Heavy-Duty Use: 1207-K-TVH-C3 Bearing
The 1207-K-TVH-C3 Bearing excels in agricultural machinery, such as grain augers, where dust and debris are common. Its open design allows for easy relubrication, extending service life in harsh conditions.

Automotive vs Aerospace: Applications of 1207-K-TVH-C3 Bearing
In automotive applications, the 1207-K-TVH-C3 Bearing supports components like alternators and water pumps. Its C3 radial clearance accommodates thermal expansion, ensuring consistent performance under varying temperatures.

Perfect Fit for Automation: 1207-K-TVH-C3 Bearing
The 1207-K-TVH-C3 Bearing is ideal for robotic arms, where its self-aligning capability reduces stress on moving parts. The lubricated design ensures quiet and efficient operation in precision automation systems.
