Self Aligning Ball Bearings 1206J

Self Aligning Ball Bearings 1206J

The 1206J is a self-aligning ball bearing with a 30mm bore and 62mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 3510 lbf and operates smoothly at speeds up to 15,000 RPM.

Its double-row design allows for slight misalignment, reducing wear and tear in uneven setups. The open seal type makes lubrication straightforward, while the steel cage ensures durability.

This bearing works well in temperatures ranging from -30°C to 110°C, suitable for various environments. It’s interchangeable with SKF models, offering a reliable replacement option.

Weighing 0.22kg, it’s a compact yet robust choice for applications like conveyor systems or electric motors where radial loads and minor misalignments are common. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 1206J
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 16 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 40.3 mm
  • Internal Diameter On Outer Ring 51.9 mm
  • Chamfer Dimension 1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 3510 lbf
  • Static Radial Load 1046 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 15000 rpm
  • Weight 0.22 kg
  • Price（$） 21.15
Self Aligning Ball Bearings 1206J dimension drawing
Download DWG Download PDF

Features

Why Choose 1206J Bearing for Precision Tasks?

1206J Bearing features a double-row design with chrome steel rings and balls, ensuring precise radial load handling.
Its dynamic radial load capacity of 3510 lbf makes it suitable for high-performance applications.
The steel cage maintains ball alignment, reducing friction and enhancing durability.
With a maximum speed of 15,000 rpm, it offers both precision and efficiency in operation.

Application

Industrial Uses of 1206J Bearing
1206J Bearing is commonly used in industrial machinery like conveyor systems and pumps, where its self-aligning feature compensates for minor misalignments. The double-row design provides reliable radial load support in demanding environments.

Where Is 1206J Bearing Used?
In automotive applications, 1206J Bearing fits well in gearboxes and wheel hubs, offering smooth rotation under radial loads. Its metric sizing ensures compatibility with a variety of vehicle designs.

Perfect Fit for Automation: 1206J Bearing
For robotic arms and automated systems, 1206J Bearing’s chrome steel construction ensures durability and consistent performance. The open seal type allows for easy lubrication, extending its service life.

Medical vs Industrial: Where 1206J Bearing Excels
While 1206J Bearing performs reliably in industrial settings, it also suits medical devices like lab equipment, where precision and low maintenance are key. The steel cage adds strength without compromising smooth operation.
